6ES7331-7KB02-0AB0 SIEMENS SIMATIC S7-300 Original Brand New

 215.33 226.67

  • 6ES7331-7KB02-0AB0
  • SIMATIC S7-300
  • Analog input SM 331
  • Isolated
  • 2 AI
  • Resolution 9/12/14 bits
  • U/I/thermocouple/resistor, alarm
  • Diagnostics, 1x 20-pole
  • Removing/inserting with active backplane bus

SIEMENS SIMATIC S7-300 – 6ES7331-7KB02-0AB0

Overview

The SIMATIC S7-300 is used in many applications worldwide and has been proven successful millions of times. The SIMATIC S7-300 universal Controllers saves on installation space and features a modular design. A wide range of modules can be used to expand the system centrally or to create decentralized structures according to the task at hand, and facilitates a cost-effective stock of spare parts. SIMATIC is known for continuity and quality.

  • Analog inputs
  • For connection of voltage and current sensors, thermocouples, resistors and resistance thermometers

Application

Analog input modules allow the connection of the PLC to analog signals of the process. They are suitable for connection of voltage transmitters and current transmitters, thermo elements, resistors and resistance thermometers.

Function

The analog input modules convert analog signals from the process into digital signals for internal processing in the PLC.

The modules feature:

  • Resolution from 9-bit to 15-bit + sign (with different conversion times), can be parameterized.
  • Different measurement ranges;
    the default setting of the current/voltage ranges is set mechanically using measuring range modules, the fine adjustment is performed with STEP 7 “Hardware configuration” via PG.
  • Interrupt capability;
    the module sends diagnostic and limit-value interrupts to the CPU of the PLC.
  • Diagnostics;
    the module sends extensive diagnostic information to the CPU.

6ES7331-7KB02-0AB0

SIMATIC S7-300, Analog input SM 331, isolated, 2 AI, Resolution 9/12/14 bits, U/I/thermocouple/resistor, alarm, diagnostics, 1x 20-pole, Removing/inserting with active backplane bus

Download

Data Sheet In PDF

Weight 0.250 kg
Dimensions 120 × 40 × 125 mm
Product Condition

Brand New, New – Backlog, New – No Original Box, New – Original Box Opened, Used – Average, Used – Below Average, Used – Excellent, Used – Fairly Good, Used – Good, Used – Poor, Used – Very Good
