7KM2200-2EA30-1DA1

Description

Overview

The Siemens SENTRON 7KM PAC2200 (7KM2200-2EA30-1DA1) is a compact, high-precision 3-phase digital power monitoring device engineered for reliable and detailed energy value recording in low-voltage power distribution systems. This standard rail instrument (DIN rail mount) is ideal for monitoring energy consumption, system state, and power quality for outgoing feeders or individual loads. Featuring an intuitive LCD display and integrated Modbus RTU communication, the PAC2200 simplifies integration into higher-level energy management and automation systems. It is a self-powered device, streamlining installation and reducing wiring complexity.

Key Features & Technical Specifications

• Product ID: 7KM2200-2EA30-1DA1
• Series: SENTRON 7KM PAC2200 Measuring Device
• Measurement: 3-phase system (via Current Transformer, 5 A rated)
• Voltage Rating: Line-to-Line (L-L: 400 V), Line-to-Neutral (L-N: 230 V)
• Energy Measurement: Apparent, Active, and Reactive Energy
• Display: LCD for real-time data viewing
• Communication: Integrated Modbus RTU interface (RS485)
• Mounting: Standard rail instrument (DIN rail mount)
• Power Supply: Self-powered (no external power supply required)
• Connection: Secure Screw terminals

Benefit & Application

• Cost Savings & Energy Efficiency: Accurately measures all essential energy types (apparent, active, reactive) to track consumption, identify waste, and support energy optimization initiatives.
• Easy Integration: The built-in Modbus RTU communication allows for quick and seamless connection to existing SCADA, BMS, or Siemens Power Monitoring software (powerconfig, powermanager).
• Simplified Installation: Designed as a compact, self-powered device for hassle-free mounting on a DIN rail using secure screw terminals.
• Global Standard: Meets high standards, including compliance with IEC 61557-12 (Class 1%), ensuring reliable and reproducible measurement results worldwide.
• Versatile Monitoring: Provides the foundation for comprehensive power data management and assessing the quality and state of your electrical network.
