1FK2204-5AF10-1MA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

1FK2204-5AF10-1MA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

The 1FK2204-5AF10-1MA0 SIMOTICS S-1FK2 Compact servo motor from SIEMENS is a precision-engineered solution for modern automation systems. Built with advanced synchronous motor technology, this exclusive unit is designed for applications where compact dimensions, high power density, and consistent performance are essential. With a rated torque of 2.4 Nm and power output of 0.75 kW at 3000 rpm, it provides the efficiency and dynamic control required for demanding motion tasks in industrial environments.

This model includes a holding brake for enhanced operational safety and reliability. The degree of protection is IP64, ensuring durability against dust and splashes. The motor comes with a robust D19x40 mm shaft with feather key for secure coupling, and features an absolute encoder with 22-bit single-turn and 12-bit multiturn resolution (AM22DQC), which delivers precise feedback for exact positioning and control. Additionally, the OCC interface and rotatable M17 plug simplify integration and connectivity, allowing quick setup in both new and existing systems.

Overview

The SIMOTICS S-1FK2 motor series is engineered for a broad range of industrial applications. Known for their compact construction and high dynamic performance, these motors provide both flexibility and resilience in continuous operation. Their optimized power density and overload capability make them a trusted choice in servo drive technology. Within this product family, the 1FK2 Compact version is ideal for tasks requiring medium to high load handling with consistent control stability.

The extended portfolio of SIEMENS 1FT2 motors complements the 1FK2 range, offering finer speed grading, broader torque options, and additional configurations. This ensures that even challenging applications can be addressed with precision and efficiency, giving users a scalable and future-proof motor platform.

SIMOTICS S-1FK2 Highlights

• High dynamic response with low inertia for fast and precise movements.
• Compact dimensions for space-saving cabinet or machine installation.
• Robust mechanical design with IP64 protection for reliable use in industrial conditions.
• Integrated absolute encoder with multiturn functionality for precision control.
• Compatible with SINAMICS S210 servo drive systems for optimized performance.

Download

Data Sheet (PDF)

Product Code: 1FK2204-5AF10-1MA0
