1FK2204-5AF10-0MB0

Description

1FK2204-5AF10-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

The SIEMENS SIMOTICS S-1FK2 servo motor with product code 1FK2204-5AF10-0MB0 is a highly reliable and compact synchronous motor designed for industrial automation. This exclusive version delivers outstanding precision and durability, offering a continuous torque of 2.4 Nm and rated power output of 0.75 kW at 3000 rpm with voltage supply between 380–480 V. At 1500 rpm, it provides 0.375 kW at 200–240 V, ensuring flexible performance across multiple applications. Equipped with a robust holding brake, cylindrical shaft (D19x40 mm), and an advanced 22-bit plus 12-bit multiturn absolute encoder (AM22DQC), this motor guarantees accurate motion control and secure operation. The integrated DRIVE-CLiQ M17 connection and IP64 protection rating further enhance safety and reliability.

Thanks to its compact build, this servo motor is well-suited for industrial systems where space-saving design and high efficiency are critical. It is engineered for seamless integration into automation networks and provides consistent performance in demanding environments. The combination of high torque density, stable control, and long-lasting durability makes it an excellent choice for industries requiring dependable servo drive technology.

Overview

The SIMOTICS S-1FK2 family of servo motors is characterized by compact dimensions, superior overload capacity, and outstanding power density. Designed for versatile use in automation, these motors provide optimal solutions for both dynamic and precise motion control. The 1FK2 models form the foundation of the SINAMICS S210 drive system, delivering efficient interaction between motor and drive. With a limited set of variants, users benefit from a simplified selection process while achieving high performance for multiple industrial requirements.

In addition, the extended 1FT2 series offers broader torque levels, refined speed gradations, and additional configuration options, making it possible to address even more specialized applications. Whether used in standard automation tasks or more demanding environments, both the 1FK2 and 1FT2 ranges ensure precise results.

SIMOTICS S-1FK2 Motor Variants

• High Dynamic: Designed with low inertia, enabling exceptional dynamic response for lightweight moving applications.
• Compact: Provides stable control for medium to heavy moving masses with balanced inertia, ensuring smooth operation.

Download

Data Sheet (PDF)

Product Code: 1FK2204-5AF10-0MB0
