1FK7032-2AK71-1RG1-ZJ25 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1RG1-ZJ25 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RG1-ZJ25 SIMOTICS S synchronous motor represents advanced engineering for precision-driven applications. Designed with compact dimensions and high-performance capabilities, this model delivers a nominal power of 0.5 kW at 6000 rpm, operating with a torque of 1.15 Nm at 100K. It operates with a 600V DC supply and features natural cooling for reliable long-term use. Built in IMB 5 design with flange mounting and a rotatable power connector, this exclusive motor provides installation flexibility while maintaining robust protection with IP65 certification.

Equipped with an absolute encoder AM20DQI, offering 20-bit single-turn and 12-bit multi-turn resolution through DRIVE-CLiQ interface, the motor ensures accurate position and speed feedback. The smooth shaft design allows seamless integration with various applications, while the ALPHA SP+ planetary gearing stage (SP 060S-MF1, ratio 7) extends functionality, ensuring high efficiency in demanding environments. This variant comes without a holding brake, which makes it especially suitable for dynamic machine axes requiring reduced inertia.

Overview

SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors that combine compact structure, wide adaptability, and premium performance. By offering compatibility with SINAMICS S120 and S220 drive systems, they provide complete motion solutions that are scalable for future machine generations. Their modular design supports multiple encoder and gearbox options, ensuring each motor can be optimized for specific industrial tasks. Heat dissipation is achieved through the motor surface, eliminating the need for external cooling and enhancing reliability.

Benefits

• Extremely high power density allows for space-saving installation.
• Available in Compact, High Dynamic, and High Inertia versions for varied use cases.
• High overload capability supports demanding industrial cycles.
• Seamless integration into machine tools, packaging, robotics, and textile applications.
• Optimized encoder options for accurate speed and position control.

Applications

• Machine tools and precision machining
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing equipment and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RG1-ZJ25
