1FK7033-4CF21-1QB0 SIEMENS Exclusive SIMOTICS S-1FK7 High Dynamic Synchronous Motor Original Brand New

1FK7033-4CF21-1QB0 SIEMENS Exclusive SIMOTICS S-1FK7 High Dynamic Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CF21-1QB0 is a premium synchronous motor from the SIMOTICS S-1FK7 High Dynamic series, engineered to deliver precision, performance, and dependability in automation environments. Designed for compact installations, this permanent-magnet motor achieves a nominal power of 0.38 kW and a torque of 1.3 Nm at 3000 rpm. Its naturally cooled IMB 5 construction ensures efficient thermal management through the motor’s outer surface, providing steady operation without external cooling components. The robust IP64 protection rating makes it suitable for a wide range of industrial environments where dust and moisture resistance are essential.

Featuring a 20-bit single-turn absolute encoder with DRIVE-CLiQ interface, the motor guarantees precise feedback for high-accuracy position and speed control. It includes a fitted-key shaft with tolerance N and an integrated holding brake, ensuring smooth and secure performance. The rotatable power connector simplifies wiring and installation, even in space-constrained machine designs. When combined with the SINAMICS S120 or S220 drive systems, the motor becomes part of a powerful, flexible solution that supports advanced motion control applications.

Overview

The SIMOTICS S-1FK7 family of motors offers compact design, exceptional dynamics, and broad configurability. Available in Compact, High Dynamic, and High Inertia versions, the range adapts seamlessly to diverse mechanical and automation needs. Each variant delivers high overload capacity and operational reliability for modern machine generations.

Benefits & Applications

• Compact size with exceptional power density
• Highly responsive motion thanks to low rotor inertia
• Reliable performance for universal industrial applications
• Reduced setup and commissioning effort
• Ideal for machine tools, robotics, packaging, and material handling
• Excellent for glass, textile, printing, and auxiliary axis systems

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CF21-1QB0
