1FK7034-2AK71-1PA1 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AK71-1PA1 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AK71-1PA1 SIMOTICS S-1FK7 synchronous motor is an advanced industrial motor designed for precise and efficient motion control. This exclusive compact motor offers 0.63 kW nominal power with a torque of 1.6 Nm and a nominal speed of 6000 rpm, delivering high accuracy and stability for a wide range of automation applications. Built with a permanent-magnet rotor, the motor operates naturally cooled and features a rugged IMB 5 construction, ensuring long-term reliability under demanding conditions.

Equipped with a 2-pole resolver and DRIVE-CLiQ interface, this motor ensures smooth communication with SINAMICS drive systems, enabling efficient synchronization and position feedback. The flange-mounted configuration with a rotatable power connector simplifies installation in confined spaces. The smooth shaft with a feather key and tolerance N allows secure coupling, while the IP65 protection rating guarantees safe operation against dust and water intrusion, making it ideal for harsh industrial environments.

Overview

SIMOTICS S-1FK7 motors are part of the next generation of compact, high-performance synchronous motors. Designed for integration with SINAMICS S120 and S220 drive systems, they provide a scalable solution suitable for modern automation environments. Available with diverse encoder options and mechanical interfaces, these motors adapt perfectly to various industrial requirements.

Benefits & Applications

• Compact and space-saving design with superior power density
• Efficient heat dissipation for stable operation without external cooling
• Compatible with SINAMICS drives for high-precision control
• Ideal for robotics, machine tools, and automated handling systems
• Suitable for woodworking, packaging, printing, and textile machines
• Minimal commissioning effort and consistent performance under load changes

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1PA1
