The SIEMENS 1FK7034-2AK71-1PB2 SIMOTICS S-1FK7 synchronous motor delivers high torque density, reliability, and flexible mounting with resolver feedback and IP65/IP67 protection for modern automation applications.
Backorder available · Factory lead time 2–3 weeks.
The SIEMENS 1FK7034-2AK71-1PB2 SIMOTICS S-1FK7 synchronous motor is a compact, high-precision drive component engineered for advanced industrial automation. Delivering a rated power of 0.63 kW and torque of 1.6 Nm at 6000 rpm, this naturally cooled motor combines efficiency, precision, and mechanical strength in a versatile design. The IMB 5 configuration enables flexible mounting options, while the IP65 degree of protection ensures reliability even in harsh operating environments. Its DE flange with IP67 protection further enhances durability and sealing performance.
This exclusive model integrates a two-pole resolver with DRIVE-CLiQ interface for accurate speed and position feedback. The motor includes a shaft with a feather key for secure coupling, plus a holding brake for added safety during stops or load holding. Its rotatable power connector simplifies installation in tight control cabinet spaces. With natural convection cooling and a robust design, the SIMOTICS S-1FK7 motor offers continuous operation and stable thermal management for consistent performance.
SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors designed for applications requiring compact size, high torque density, and superior control precision. Available in a wide range of mechanical versions and equipped with multiple encoder options, these motors adapt seamlessly to a variety of industrial setups. When combined with SINAMICS S120 or S220 drive systems, they deliver a flexible and powerful automation platform with optimized energy efficiency and system integration.
Product Code: 1FK7034-2AK71-1PB2
More Siemens products at Turll.com
| SKU / Model | 1FK7034-2AK71-1PB2 |
|---|---|
| Weight | 4.1 kg |
