1FK7040-2AK71-1QG1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,168.44
The SIEMENS SIMOTICS S 1FK7040-2AK71-1QG1 synchronous motor delivers exceptional precision and performance for advanced automation systems. With 0.69 kW power, 1.6 Nm torque, and 6000 rpm speed, this compact motor ensures efficiency, reliability, and durability in demanding industrial environments.
1FK7040-2AK71-1QG1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7040-2AK71-1QG1 is a premium compact synchronous motor designed for high-performance motion control in modern automation environments. This advanced motor delivers a nominal power of 0.69 kW with a rated speed of 6000 rpm and a torque of 1.6 Nm at 100K. Featuring a 600V DC supply, naturally cooled operation, and IP65 degree of protection, it ensures reliable performance even under challenging industrial conditions. The design includes a rotatable power connector, smooth shaft with tolerance N, and an absolute single-turn 20-bit encoder (AS20DQI) with DRIVE-CLiQ interface for precise position and speed control. Compact yet powerful, it combines high efficiency with long-lasting durability.
Overview
The SIMOTICS S-1FK7 series represents a new generation of permanent-magnet synchronous motors developed for maximum flexibility and performance. These motors are highly compact, offering excellent power density for space-saving installations. With various available options—gearboxes, encoder systems, and shaft designs—they can be tailored precisely to meet a wide range of industrial requirements. The 1FK7040-2AK71-1QG1 motor integrates seamlessly with SIEMENS SINAMICS S120 and S220 drive systems, delivering a robust, efficient, and intelligent motion control solution. The integrated encoder system provides accurate feedback for superior dynamic response and positioning accuracy, making it ideal for precision-driven applications.
Benefits
- Compact Design: High power density ensures efficient use of installation space.
- Versatile Applications: Suitable for a wide range of industrial systems.
- Excellent Performance: High torque output with smooth and consistent operation.
- Advanced Control: Integrated encoder enhances speed and position accuracy.
- Reliable Durability: IP65 protection and maintenance-free operation for long service life.
Applications
The SIMOTICS S 1FK7 motors are widely used in applications that require precision, efficiency, and reliability. These include machine tools, robotics, packaging systems, and industrial automation equipment. They are also suitable for use in printing, textile, and plastic processing machines, as well as wood, glass, and ceramic machinery. With a strong focus on energy efficiency and motion accuracy, the 1FK7040-2AK71-1QG1 motor ensures optimized performance across diverse industrial environments.
Download
Product Code: 1FK7040-2AK71-1QG1
More Siemens products at Turll.com
| Weight | 3.201 kg |
|---|
