1FK7060-2AF71-1UA2-ZK24 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

1FK7060-2AF71-1UA2-ZK24 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

The SIEMENS 1FK7060-2AF71-1UA2-ZK24 motor is part of the high-quality SIMOTICS S-1FK7 series, an advanced line of synchronous motors engineered for demanding motion control environments. This version delivers a rated torque of 6 Nm and operates efficiently with a 600 V DC supply. Designed with a naturally cooled structure and an IMB 5 mounting style, it integrates seamlessly into diverse machine configurations. It is equipped with a multi-pole resolver using DRIVE-CLiQ communication, ensuring precise position feedback and reliable synchronization within complex drive systems.

The rotatable power connector enhances installation flexibility while the IP65/IP67 protection concept ensures durability in challenging industrial conditions. The K24 variant features a primed surface without final paint finish, suitable for applications requiring custom coating or specialized environmental preparation.

The motor’s high power density supports compact machine layouts, while its stable performance profile makes it suitable for continuous operation under varying mechanical loads. With its feather-key shaft and absence of a holding brake, this unit is optimized for dynamic applications where smooth rotation and fast response are essential. The SIMOTICS S-1FK7 line is recognized for its efficient torque delivery, robust mechanical build, and compatibility with advanced automation systems. When paired with SINAMICS S120 or S220 drives, the motor enables high-precision movement, coordinated motion sequences, and fast control cycles across a wide spectrum of industries.

Overview

The SIMOTICS S-1FK7 series includes compact permanent-magnet synchronous motors designed for adaptable performance across modern machine generations. Various encoder options and gearbox interfaces allow these motors to be tailored to application-specific requirements. Integrated encoder technologies support accurate speed and position regulation, and the design allows the motor to dissipate heat efficiently through its external surface. High overload capacity and excellent control behavior make the series ideal for machines requiring stable and dynamic operation.

Benefits

The compact variants offer space-saving installation and support a wide selection of configurations. The high-dynamic versions provide exceptional acceleration due to reduced rotor inertia, while the high-inertia designs deliver reliable closed-loop characteristics for processes involving fluctuating loads. Minimal commissioning effort, combined with compatibility across diverse automation environments, enhances operational efficiency.

Application

These motors are widely used in machine tools, handling systems, robotics, woodworking machinery, printing systems, and numerous auxiliary axis applications across many industrial sectors.

Download

Data Sheet (PDF)

Product Code:
1FK7060-2AF71-1UA2-ZK24
