1FK7062-2AC71-1QH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1QH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1QH2 SIMOTICS S motor is engineered to deliver reliable motion performance for advanced industrial applications requiring precision, endurance, and smooth operation. As part of the SIMOTICS S-1FK7 CT family, this motor provides a rated power of 1.5 kW, nominal torque of 8.5 Nm, and a base speed of 2000 rpm. Its naturally cooled construction enhances thermal stability, allowing it to perform effectively in demanding environments while maintaining consistent efficiency across a broad range of duty cycles.

Equipped with a single-turn 20-bit absolute encoder featuring the Drive-CLiQ interface (AS20DQI), the model supports accurate positioning and continuous feedback essential for modern automation systems. The smooth shaft with tolerance class N promotes low-friction, reliable rotation, complementing the included holding brake for controlled motion and secure static stopping. The unit’s robust protection rating of IP65, with the DE flange reaching IP67, underlines its suitability for facilities where dust, moisture, or aggressive operating conditions are present.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to integrate seamlessly into diverse automation platforms. With a modular structure, multiple encoder types, and various mechanical configurations, these motors can be tailored to a wide range of technical requirements. Their compatibility with SINAMICS S120 and S220 drive systems expands their operational capabilities, enabling precise closed-loop control and enhanced dynamic response.

The motors are optimized for operation without external cooling systems, relying instead on surface heat dissipation. This promotes durability without adding mechanical complexity. High overload capacity further strengthens their suitability for applications requiring fast acceleration or frequent load variations.

Design & Key Features

• 1.5 kW rated power with stable natural cooling
• 20-bit absolute encoder (AS20DQI) with Drive-CLiQ communication
• Smooth shaft, tolerance class N for low-vibration rotation
• Holding brake for stable positioning when idle
• IP65 body protection, IP67 DE flange protection
• Rotatable power connector and IMB 5 mounting design
• Suitable for universal, dynamic, and high-inertia applications

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1QH2
