1FK7062-2AC71-1UA1 SIEMENS Exclusive Synchronous Motor Original Brand New

1FK7062-2AC71-1UA1 SIEMENS Exclusive Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1UA1 is a precision-engineered synchronous motor developed for industrial environments where accuracy, torque stability, and long-term durability are essential. As a member of the SIMOTICS S-1FK7 product line, this motor is built with a compact design that supports effortless integration into diverse machine architectures. Delivering a rated power of 1.5 kW and operating at 2000 rpm, it maintains consistent performance even under challenging operating conditions. The naturally cooled configuration ensures efficient heat dissipation through the motor surface, keeping the system reliable without requiring auxiliary cooling devices.

The unit features a multi-pole resolver equipped with a DRIVE-CLiQ interface, enabling precise feedback for position and speed control. This seamless connection improves communication with SINAMICS drives, resulting in efficient operation and smooth motion control. A rotatable power connector adds flexibility during installation, while its IP65 protection rating enhances resistance to dust and moisture. The shaft with feather key and tolerance class N provides secure torque transfer, making the motor suitable for a wide variety of automation tasks.

Overview

The SIMOTICS S-1FK7 product family combines compact dimensions with high-performance characteristics, making it adaptable for many industrial sectors. Its modular design includes various encoders, mechanical options, and gearbox combinations, enabling customization according to application requirements. When paired with SINAMICS S120 or S220 drive systems, the motors form a robust and highly responsive automation package capable of delivering advanced control functionality.

Key Features

• Compact construction with high power density for reduced installation space
• Options for various applications ranging from standard to high-dynamic systems
• High overload capacity for demanding production cycles
• Surface cooling design eliminates the need for external cooling devices
• Stable closed-loop behavior under varying load conditions

These motors are widely used in robotics, machine tools, packaging lines, printing systems, and material-processing equipment such as wood, glass, and ceramic machinery. Their combination of precision, adaptability, and endurance supports efficient machine operation across numerous industries.

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1UA1
