6AG1322-5HF00-4AB0 Siemens SIPLUS S7-300 SM 322
6AG1322-5HF00-4AB0 Siemens SIPLUS S7-300 SM 322
6AG1322-5HF00-4AB0 Siemens SIPLUS S7-300 SM 322
6AG1322-5HF00-4AB0 Siemens SIPLUS S7-300 SM 322

6AG1322-5HF00-4AB0 Siemens SIPLUS S7-300 SM 322 Original Brand New

Model / SKU6AG1322-5HF00-4AB0

6AG1322-5HF00-4AB0

Siemens SIPLUS S7-300 SM 322 8RO 40pol based on 6ES7322-5HF00-0AB0 with conformal coating, 0…+60 °C, digital output isolated, 8 DQ (relay), 1x 40-pole, 24 V DC, 120-230 V AC, 5 A with RC filter overvoltage protection

$808.26
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

[ez-toc]

Overview

  • Digital outputs
  • For connecting solenoid valves, contactors, small-power motors, lamps and motor starters
Note:

SIPLUS extreme products are based on SIMATIC standard products. The contents listed here were taken from the respective standard products. SIPLUS extreme-specific information was added.

Application

Digital output modules permit the output of digital signals from the PLC to the process by converting the internal signal level of the S7-300 into the external signal level required by the process.

They are suitable for connecting solenoid valves, contactors, small-power motors, lamps and motor starters, for example.

Design

Digital output modules feature the following mechanical characteristics:

  • Compact design:
    • Green LEDs for indicating the signal status at the outputs.
    • Socket for the front connector, protected, behind the front door.
    • Labeling field on the front door.
    • Connector pin assignment for the wiring on the inside of the front door.
  • Easy installation:
    There are no slot rules, the addresses of the outputs are determined by the slot.
    When used in ET 200M in combination with active bus modules, hot swapping is possible without any reaction.
  • User-friendly wiring.
  • RC filter (for relay module 6ES7 322-1HF20):
    Relay module 6ES7 322-1HF20-0AA0 has a connectable RC damping network (300 Ω/0.1 μF) for reducing the arcing at the contacts when large inductive loads are switched (power factor = 0.4). This results in, for example:

    • An increase in the service life of the contacts from 100,000 to 200,000 switching cycles when a motor starter for a NEMA motor of frame size 5 is activated.

The modules are available with 8, 16, 32, or 64 channels.

Function

Digital output modules convert the internal signal level of the controller (logical "0" or "1") to the external signal level required by the process.

Various output voltages support the output of different process signals:

  • 24 V DC, rated current 0.5 A/channel
  • 24 V DC, rated current 2 A/channel
  • 48 to 125 V DC
  • 120/230 V AC

Apart from cost-effective, easy-to-handle digital output modules, modules with special functions are also available for process engineering.

6AG1322-5HF00-4AB0

Siemens SIPLUS S7-300 SM 322 8RO 40pol based on 6ES7322-5HF00-0AB0 with conformal coating, 0…+60 °C, digital output isolated, 8 DQ (relay), 1x 40-pole, 24 V DC, 120-230 V AC, 5 A with RC filter overvoltage protection

Visit 6AG1322-5HF00-4AB0

For more our products visit turll.com

Specifications

SKU / Model6AG1322-5HF00-4AB0
Weight0.356 kg
Dimensions150 × 130 × 48 mm
