The SIEMENS 6DR5020-0EG00-0AA0 SIPART PS2 is a smart electropneumatic positioner built for precise control in pneumatic linear or part-turn actuators. This high-performance device supports a 4–20 mA input signal and is housed in a durable polycarbonate enclosure. It features wear-free, non-contacting position detection (NCS) and is intrinsically safe (Ex i) for hazardous environments.

Designed to enhance process automation efficiency, the SIPART PS2 delivers superior performance with intelligent diagnostics, fail-safe depressurization on auxiliary power loss, and optional modular expansions such as Analog Output, Digital I/O, and limit switches. This model does not include a manometer, venting gauge block, booster, or optional modules, ensuring a compact and cost-effective base unit.

Overview

SIPART PS2 positioners regulate the actuator’s position in accordance with the setpoint, ensuring responsive and accurate valve control. Built-in diagnostic capabilities allow for condition monitoring both online and offline. When equipped with additional pressure sensors, diagnostics can be extended to further optimize system reliability.

Design

The SIPART PS2 includes:

• Polycarbonate enclosure with or without inspection window
• Electronics supporting 4–20 mA, HART, PROFIBUS PA, or FOUNDATION Fieldbus
• Non-contacting position feedback (NCS) or potentiometer
• Pneumatic block with side-mounted air connections (G 1/4")
• Support for gauge block, booster, solenoid valve, and other optional modules

Optional modules (not included in this model) offer:

• Analog Output (4–20 mA position feedback)
• Digital I/O for limit signaling, alarms, and safety responses
• Inductive or mechanical limit switches with NAMUR compatibility

Separate Mounting

The SIPART PS2 allows remote mounting for applications where ambient conditions are unsuitable. This enables the positioner to be installed in protected areas while the position detection remains at the actuator. Electrical and pneumatic connections are made via cables and tubing.

Product Code: 6DR5020-0EG00-0AA0
