Siemens 5SJ4106-7HG41 Sentron Miniature Circuit Breaker 1-Pole, 6 Amp, Type C, UL 489 Rated
Siemens 5SJ4106-7HG41 Sentron Miniature Circuit Breaker 1-Pole, 6 Amp, Type C, UL 489 Rated
Siemens 5SJ4106-7HG41 Sentron Miniature Circuit Breaker 1-Pole, 6 Amp, Type C, UL 489 Rated
Siemens 5SJ4106-7HG41 Sentron Miniature Circuit Breaker 1-Pole, 6 Amp, Type C, UL 489 Rated
Siemens 5SJ4106-7HG41 Sentron Miniature Circuit Breaker 1-Pole, 6 Amp, Type C, UL 489 Rated

SIEMENS

Siemens 5SJ4106-7HG41 Sentron Miniature Circuit Breaker 1-Pole, 6 Amp, Type C, UL 489 Rated Original Brand New

Model / SKU5SJ4106-7HG41

High-performance 1-pole miniature circuit breaker (MCB) designed for branch circuit protection. Featuring a 6A current rating and a Type C tripping characteristic, this 240V unit provides a 14kA interrupting capacity and is fully compliant with UL 489 standards for North American industrial applications.

Original price was: $116.91.Current price is: $58.79.
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 5SJ4106-7HG41 is part of the trusted Sentron series, engineered specifically for demanding industrial and commercial environments. This MCB acts as a critical safety component, protecting electrical installations from overloads and short circuits. Because it meets UL 489 standards, it is approved for use as a branch circuit protector, ensuring compliance with strict electrical codes.

Key Benefit

  • Global Compliance: Certified according to UL 489 and CSA C22.2, making it suitable for export and global machinery standards.

  • High Interrupting Capacity: Capable of handling fault currents up to 14kA at 240V AC.

  • Space-Saving Design: With a mounting depth of 70mm, it fits easily into standard distribution boards and control panels.

  • Enhanced Safety: The Type C trip curve is ideal for circuits with moderate inrush currents, such as lighting and small motor loads.

Function & Features

  • Pole Configuration: 1-Pole (Single phase protection).

  • Tripping Characteristic: Type C (Trips between 5x and 10x rated current).

  • Mounting: Standard DIN Rail mounting for quick installation.

  • Application: Specifically designed for "Branch Circuit Protection" in panels.

Ideal For

  • Residential electrical panels

  • Commercial building wiring systems

  • Industrial control panels

  • Renovations and retrofits

  • First‑time installations and replacements

Visit 5SJ4106-7HG41 for more detail info

For more our products visit turll

Download

Datasheet in PDF

Specifications

SKU / Model5SJ4106-7HG41
BrandSIEMENS
product brand nameSENTRON
product designationMiniature circuit breakers
design of the productMiniature circuit-breaker 5SJ4
number of poles1
tripping characteristic classC
mechanical service life (switching cycles) / typical10 000
installation environment regarding EMCSuitable for environment B (immunity to interference not applicable)
reference code / acc. to DIN 40719 extended according to IEC 204-2 / acc. to IEC 750F
overvoltage category3
degree of pollution3
insulation voltage (Ui) / at AC / rated value440 V
supply voltage / at AC / rated value400 V
operating voltage-
● at AC / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum240 V
● at DC / rated value / maximum60 V
● at DC / single channel / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum60 V
● at DC / 2-channel / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum125 V
protection class IPIP20, with connected conductors, IP 40 in the handle range
switching capacity current-
● acc. to EN 60898 / rated value10 kA
● acc. to IEC 60947-2 / rated value15 kA
power loss [W] / for rated value of the current / at AC / in hot operating state / per pole2.7 W
operational current-
● at 30 °C / rated value6 A
● at 40 °C / rated value6 A
● at 45 °C / rated value5.8 A
● at 50 °C / rated value5.7 A
● at 55 °C / rated value5.6 A
● at 60 °C / rated value5.4 A
● at AC / rated value6 A
type of voltage supply / at AC / acc. to UL 489 and CSA C22.2 No. 5-02240
suitability for operationMechanical engineering / industry
product component / neutral conductor switchingNo
product feature / touch protectionYes
product component-
● tunnel terminals topNo
● tunnel terminals bottomNo
● combined terminal topYes
● combined terminal bottomYes
product feature-
● halogen-freeYes
● sealableYes
● silicon-freeYes
product extension / installable / supplementary devicesYes
product function / noteTerminal tightening torque for Cu, 60/75°C; 3.5Nm/31lb.in
breaking capacity short-circuit current (Icn) / at AC / acc. to UL 1077 and CSA C22.2 No.23514 kA
connectable conductor cross-section / finely stranded / with core end processing-
tightening torque / with screw-type terminals / maximum3.5 N·m
position / of power supply cordAny
installation depth70 mm
number of modular width units1
fastening methodon standard mounting rail
mounting positionany
vibration resistance50 m/s² at 25 to 150Hz and 60m/s² at 35Hz (4sec)
ambient temperature / during operation-
ambient temperature / during storage-
● minimum-40 °C
● maximum75 °C
reference code-
● acc. to DIN EN 61346-2F
● acc. to IEC 81346-2F
Test Certificatesother
Special Test CertificateMiscellaneous
Weight0.170 kg
Dimensions23.00 × 114.00 × 84.00 mm
