1FK2104-5AK01-1MA0

Description

1FK2104-5AK01-1MA0 SIEMENS Exclusive SIMOTICS S Servo Motor Original Brand New

The SIEMENS 1FK2104-5AK01-1MA0 is a high-performance servomotor from the SIMOTICS S-1FK2 HD portfolio, engineered for demanding industrial motion control tasks. Designed with efficiency, accuracy, and durability in mind, this motor provides stable mechanical performance across a wide range of automation environments. Its compact structure allows flexible installation, while its powerful torque generation supports dynamic movement without compromising stability. The motor achieves 2.4 Nm of continuous torque, delivering reliable output in systems that require smooth, consistent operation under varying loads.

Rated at 1.07 kW for 6000 rpm operation at 380–480 V and 0.75 kW at 3000 rpm for 200–240 V operation, the motor adapts effectively to different voltage systems. A robust IP65 protection rating ensures dependable use in environments with dust or moisture exposure. The shaft with feather key provides secure mechanical coupling, enhancing transmission efficiency in precision-oriented applications. With its AM22DQC absolute encoder system, offering 22-bit single-turn plus 12-bit multiturn capability, it ensures high-resolution position feedback for advanced control systems.

The rotatable M17 plug and OCC interface support streamlined integration into automated systems where cable management, connectivity, and configuration flexibility are crucial. As part of the SIMOTICS S-1FK2 family, this model is designed to meet evolving industrial challenges by offering high power density, dynamic behavior, and excellent overload capacity.

Overview

SIMOTICS S-1FK2 motors are compact synchronous servomotors designed for versatility and precision across industrial automation. Their high dynamic response makes them suitable for applications requiring rapid acceleration and consistent control accuracy. These motors integrate seamlessly with the SINAMICS S210 servo drive system, forming a performance-driven servo solution for modern machine architectures.

The extended 1FT2 variants complement the 1FK2 portfolio, offering additional torque levels, refined speed ratings, and wider configuration options to meet specialized industrial automation requirements.

Design

The SIMOTICS S-1FK2 design concept centers on efficiency, adaptability, and mechanical stability. High Dynamic versions provide rapid motion capability through minimized inertia, while Compact versions deliver dependable control for applications involving medium to high load masses. Key design advantages include rapid control cycles, high pulse frequencies, advanced regulation algorithms, and robust encoder technology.

Download

Data Sheet (PDF)

Product Code: 1FK2104-5AK01-1MA0
