1FK2204-5AK00-1SB0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

1FK2204-5AK00-1SB0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

The SIEMENS SIMOTICS S-1FK2 servo motor with product code 1FK2204-5AK00-1SB0 is a compact and high-performance synchronous motor designed to deliver reliable motion control across a wide range of industrial applications. Offering a continuous torque of 2.4 Nm and rated power output of 0.57 kW at 6000 rpm (380–480 V) or 0.75 kW at 3000 rpm (200–240 V), this model is optimized for flexibility and efficiency. With IP64 degree of protection, a D19x40 mm shaft with feather key, and an integrated absolute single-turn encoder (22-bit, encoder AS22DQC), the motor provides precise feedback and consistent operation. The integrated DRIVE-CLiQ interface and M17 connectors ensure seamless connectivity within automation environments.

Engineered as part of the SIMOTICS S-1FK2 family, this exclusive motor is built to meet modern challenges in servo drive technology. It is ideal for pairing with SINAMICS S210 servo drive systems, creating a highly dynamic and robust drive solution. Compact in design yet powerful in performance, the motor enables fast acceleration, accurate positioning, and dependable control even under demanding operating conditions. Its versatility makes it suitable for both lightweight, highly dynamic applications and medium-inertia requirements where stable control is essential.

Overview

The SIMOTICS S-1FK2 series combines high dynamic response, compact construction, and strong overload capability. The limited number of variants simplifies product selection and ensures efficient integration into existing systems. As the core motor series within SIEMENS motion solutions, it offers both flexibility and reliability for industrial automation.

The extended SIMOTICS S-1FT2 portfolio builds upon the 1FK2 design, providing additional torque levels, refined speed ranges, and a wider variety of options. This allows companies to meet more specialized requirements, including challenging environmental conditions and demanding precision tasks.

SIMOTICS S-1FK2 High Dynamic Motors

These motors are optimized for applications with low inertia and rapid motion requirements. They deliver maximum acceleration and responsiveness, making them ideal for fast-moving systems where speed and accuracy are critical.

SIMOTICS S-1FK2 Compact Motors

Compact variants are designed for stable control with medium to high load inertia. They ensure precise performance and energy efficiency, making them a reliable solution for a broad spectrum of industrial uses.

Download

Data Sheet (PDF)

Product Code: 1FK2204-5AK00-1SB0
