1FK7022-5AK71-1DB5 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

1FK7022-5AK71-1DB5 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

The SIEMENS 1FK7022-5AK71-1DB5 SIMOTICS S-1FK7 Compact servo motor is a premium synchronous motor designed to deliver exceptional efficiency, precision, and reliability in modern industrial environments. With a rated torque of 0.85 Nm, nominal power of 0.38 kW, and operating speed of 6000 rpm, this motor ensures powerful performance while maintaining compact dimensions for space-saving installation. It is naturally cooled and comes with power and signal connectors that can be rotated by 270° for maximum flexibility during installation.

The motor is designed with a flange-mounted structure (IMB5, IMV1, IMV3), features a shaft with fitted key, and includes an incremental encoder with 2048 pulses per revolution, integrated via DRIVE-CLiQ interface. For additional safety, it includes a holding brake, offering secure positioning in demanding applications.

Protected with IP65 housing and IP67 flange, the SIMOTICS S-1FK7 motor is built for harsh industrial conditions, ensuring long-term reliability. Its RAL7016 paint finish further enhances durability against environmental factors. As part of the SIMOTICS S-1FK7 portfolio, this motor is compatible with the SINAMICS S120/S220 drive systems, creating a fully integrated solution for advanced automation requirements. High overload capability, combined with a robust synchronous design, makes this motor suitable for high-speed, high-precision tasks in machine building and process automation.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for universal applications. The broad range of variants, encoder options, and gearbox compatibility allows for easy adaptation to multiple use cases. With integrated encoder systems for speed and position control, these motors are suitable for machine tools, robotics, packaging equipment, and other industries requiring accuracy and dynamic motion. Their natural cooling system ensures reliable heat dissipation through the motor surface, minimizing the need for external cooling solutions.

Benefits

• Compact motors with extremely high power density for space-efficient installation.
• High Dynamic variants provide exceptional responsiveness due to low rotor inertia.
• High Inertia versions offer robust closed-loop control for heavy or variable load conditions.
• Wide range of applications from robotics and handling systems to woodworking, printing, and textile machinery.
• Minimal commissioning effort thanks to pre-optimized design, reducing time and cost for integration.

Product Code: 1FK7022-5AK71-1DB5
