1FK7032-2AF21-1CH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1CH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1CH2 belongs to the renowned SIMOTICS S-1FK7 family of synchronous motors, engineered to deliver compact design, high reliability, and exceptional performance for modern industrial applications. With a nominal power of 0.31 kW and torque rating of 1.2 Nm at 3000 rpm, this motor is ideal for precise and demanding motion control tasks. It is naturally cooled, features a smooth shaft with a holding brake, and ensures long-lasting protection with IP65 housing and IP67 protection at the drive end flange.

Equipped with a 24-bit absolute multi-turn encoder with DRIVE-CLiQ interface (AM24DQI), the motor enables precise position feedback and seamless integration into automation systems. The rotatable power connector and compact IMB 5 mounting design make installation flexible and user-friendly. These design elements, combined with SIEMENS’ innovative engineering, guarantee efficiency, durability, and adaptability for a wide range of industrial requirements.

Overview

SIMOTICS S-1FK7 motors are permanent-magnet synchronous units developed to provide exceptional dynamic response, high overload capability, and energy-efficient operation. Their modular design allows adaptation with various gearboxes and encoders, making them suitable for multiple machine concepts. Combined with SINAMICS S120/S220 drive systems, they form a powerful automation solution with extensive functionality and intelligent control options.

Benefits

• Extremely high power density for space-saving installation
• Universal applications across industries
• High Dynamic version ensures rapid acceleration and responsiveness
• High Inertia version guarantees stability under varying loads
• Reduced commissioning effort with robust closed-loop control

Applications

• Machine tools and robotics
• Handling and automation systems
• Packaging, printing, and textile machinery
• Wood, glass, ceramics, and stone processing
• Auxiliary axes requiring reliable performance

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1CH2
