1FK7032-2AF21-1FH1-ZJ33 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1FH1-ZJ33 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1FH1-ZJ33 SIMOTICS S synchronous motor is a premium solution engineered for modern industrial automation. This compact motor delivers a rated power of 0.31 kW at 300 V DC and provides a torque of 1.2 Nm at 3000 rpm under 100K operating conditions. Designed with natural cooling and equipped with a rotatable power connector, the motor ensures adaptability in various mechanical environments. Its high-resolution absolute encoder AM22DQ with DRIVE-CLiQ interface, featuring 22-bit single-turn and 12-bit multi-turn functionality, guarantees precise feedback for accurate motion control.

The motor comes with a plain shaft and a holding brake for enhanced safety and stability in demanding applications. The degree of protection is IP65, offering resilience against dust and water ingress, making it suitable for industrial operations. This model is supplied with an integrated planetary gear unit ALPHA SP+, SP 060S-MF2, two-stage, ratio i=20, ensuring efficient power transmission and reliable performance without the use of a feather key.

Overview

SIMOTICS S-1FK7 motors are known for their compact design, high power density, and versatility. They support a wide variety of applications thanks to their compatibility with SINAMICS S120 and S220 drive systems. With multiple gearbox and encoder options, these motors can be configured for different industrial needs while providing excellent overload capacity and stable operation.

Benefits

• Space-saving installation with high power density
• Reliable performance for universal applications
• Flexible range of compact, high dynamic, and high inertia designs
• Excellent closed-loop control even under fluctuating load conditions
• Reduced commissioning efforts with integrated encoders

Applications

• Machine tools and robotic systems
• Packaging, plastics, and textile machinery
• Printing machines
• Wood, glass, ceramics, and stone processing
• Auxiliary axes in automation environments

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1FH1-ZJ33
