1FK7032-2AF21-1PA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1PA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1PA0 belongs to the SIMOTICS S-1FK7 series, a family of high-performance synchronous motors built for precision, efficiency, and versatility in industrial automation. With a rated power of 0.31 kW, rated torque of 1.2 Nm, and a speed of 3000 rpm, this compact motor is designed to deliver dependable performance in a wide range of machine applications. The natural cooling system and IP64 protection rating ensure durability and long service life, even under demanding operating conditions. Its flange-mounted IMB 5 design with a rotatable power connector makes installation simple and flexible, while the integrated DRIVE-CLiQ interface enhances connectivity with SINAMICS drive systems.

The SIMOTICS S-1FK7 motors are widely recognized for their compact size, high torque density, and adaptability. They can be combined with SINAMICS S120 or S220 drive systems to create powerful motion control solutions with advanced functionality. The built-in encoder systems offer precise speed and position control, making the motor suitable for applications that require high accuracy and reliability. Thanks to its overload capability and surface cooling design, the motor can handle continuous operation with minimal downtime.

Overview

SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors available in compact, high dynamic, and high inertia variants. They are ideal for universal use across multiple industries, offering flexibility and performance tailored to modern machinery requirements. The wide range of options, including gearboxes and encoder types, makes these motors a future-proof investment for manufacturers seeking efficiency and precision.

Benefits

• Space-saving installation due to high power density
• Excellent flexibility for universal applications
• High dynamic response with low rotor inertia
• Robust closed-loop control properties for variable loads
• Minimal commissioning and maintenance effort

Applications

• Machine tools and robotics
• Packaging, plastics, and textile machinery
• Wood, glass, ceramics, and stone processing
• Printing systems and auxiliary machine axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1PA0
