The SIEMENS 1FK7032-2AK71-1CG0-ZV40 SIMOTICS S synchronous motor delivers 0.5 kW power, 6000 rpm speed, IP64 protection, and integrated planetary gearbox, making it an ideal solution for high-precision industrial applications.
The SIEMENS 1FK7032-2AK71-1CG0-ZV40 SIMOTICS S synchronous motor represents the latest generation of compact drive technology engineered for precision, efficiency, and reliability. Designed with a continuous power output of 0.5 kW, a rated speed of 6000 rpm, and natural cooling, this motor is optimized for consistent performance in demanding environments. It features an absolute encoder with 24-bit single-turn plus 12-bit multi-turn resolution via DRIVE-CLiQ interface, ensuring highly accurate position and speed feedback. The smooth shaft configuration without a holding brake, combined with its IP64 protection rating, makes it suitable for diverse industrial settings where durability and precision are critical.
One of the highlights of this variant is the integrated planetary gearbox ALPHA LP+ LP 070-MO1, providing a gear ratio of 1:5 with a fitted key. This gearing solution increases torque capacity, offering stable and efficient power transmission for applications that require accuracy and robustness. With a rotatable power connector and flexible IMB 5 mounting design, the motor can be seamlessly integrated into multiple mechanical layouts.
SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for versatility. Their modular structure allows for customization with different encoders, gear units, and mechanical interfaces, making them adaptable to the needs of advanced machinery. Combined with SINAMICS S120 or S220 drive systems, these motors deliver high functionality and seamless communication in modern automation environments.
Product Code: 1FK7032-2AK71-1CG0-ZV40
More Siemens products at Turll.com
| SKU / Model | 1FK7032-2AK71-1CG0-ZV40 |
|---|---|
| Weight | 4.601 kg |
Request a quote for project quantities, discontinued or obsolete models, and pro-forma invoice / bank transfer orders. Our sourcing team responds fast.
