1FK7032-2AK71-1CH1-ZJ16 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1CH1-ZJ16 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1CH1-ZJ16 is an exclusive synchronous motor designed as part of the highly reliable SIMOTICS S-1FK7 series. This motor is engineered for precision, efficiency, and durability, making it an ideal choice for a wide variety of industrial applications. With a rated power output of 0.5 kW, a continuous torque of 1.15 Nm at 100K, and a nominal speed of 6000 rpm, it is well-suited for applications that demand high dynamics and stable performance. Featuring natural cooling and a compact IMB 5 design, the motor ensures long service life and operational efficiency in demanding environments.

The motor comes with a smooth shaft design, holding brake, and a 24-bit + 12-bit multi-turn absolute encoder using DRIVE-CLiQ interface for precise motion control. Its high degree of protection (IP65) makes it robust for use in environments with dust and splashes, ensuring reliable operation even in tough conditions. With a flange-mounted power connector that can be rotated, it offers greater flexibility during installation. Additionally, this unit includes the ALPHA SP+ planetary gearbox with a two-stage configuration, gear ratio of 40, and feather key design, ensuring efficient power transmission and mechanical stability.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for universal use. Thanks to a wide variety of encoder and gearbox options, they can be tailored to match the specific needs of advanced machine generations. These motors are optimized for seamless integration with SINAMICS S120 and S220 drive systems, creating a powerful combination of performance and reliability. With their high overload capability and design for natural cooling, they provide dependable operation with minimal maintenance requirements.

Benefits

• Compact structure with high power density for space-saving installation
• Universal adaptability across multiple industrial applications
• Dynamic response with minimal rotor inertia for precision control
• Robust performance for variable load conditions
• Reduced commissioning effort with optimized disturbance compensation

Applications

• Machine tools and CNC machinery
• Robotics and automated handling systems
• Woodworking, glass, ceramics, and stone processing equipment
• Packaging, plastics, and textile machines
• Printing presses and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1CH1-ZJ16
