1FK7032-2AK71-1CH1-ZJ33 SIEMENS Exclusive SIMOTICS S Synchronous Motor with Gearbox Original Brand New
$4,502.11
The SIEMENS 1FK7032-2AK71-1CH1-ZJ33 SIMOTICS S synchronous motor with integrated gearbox delivers high precision, compact design, and reliable performance for automation and machinery applications.
1FK7032-2AK71-1CH1-ZJ33 SIEMENS Exclusive SIMOTICS S Synchronous Motor with Gearbox Original Brand New
The SIEMENS 1FK7032-2AK71-1CH1-ZJ33 is a premium SIMOTICS S-1FK7 synchronous motor that combines compact design, reliable performance, and flexible integration for a wide range of automation solutions. Built to meet the needs of modern industrial environments, this exclusive motor provides excellent efficiency with a rated power of 0.5 kW, torque of 1.15 Nm, and speed of up to 6000 rpm.
With natural cooling and a robust IMB 5 flange design, it is well suited for applications where reliability, precision, and durability are critical. The motor includes an advanced absolute encoder with DRIVE-CLiQ interface and features a holding brake for safe operations. Additionally, this version is equipped with an ALPHA SP+ planetary gearbox, offering a two-stage reduction ratio of 20 for greater mechanical performance.
Designed for use with SINAMICS drive systems, this synchronous motor ensures seamless operation in demanding production environments. The IP65 protection rating safeguards the motor against dust and water, making it highly reliable even under challenging conditions. Its combination of compact size, flexible encoder options, and gearbox integration makes it an excellent solution for machine builders who require both precision and versatility in their systems.
Overview
SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors that can be customized with a wide range of encoders and gearboxes. Their modular design allows adaptation to various applications, meeting the high demands of new machine generations. When combined with SINAMICS drives, they form a powerful, high-functionality system that ensures precision control, fast response, and robust performance across industries.
Benefits
- Space-saving construction with very high power density
- Versatile options for universal industrial applications
- Wide product range covering compact, high dynamic, and high inertia variants
- Excellent overload capacity and dependable heat dissipation through motor housing
- Reliable closed-loop control properties for demanding load conditions
Application
- Machine tools and precision automation equipment
- Robotics, handling systems, and packaging machinery
- Textile, plastics, and printing applications
- Wood, glass, ceramics, and stone processing
- Auxiliary and secondary axes in multi-axis systems
Download
Product Code: 1FK7032-2AK71-1CH1-ZJ33
More Siemens products at Turll.com
| Weight | 5 kg |
|---|
