1FK7032-2AK71-1FA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,951.35
The SIEMENS 1FK7032-2AK71-1FA2 SIMOTICS S synchronous motor delivers 0.5 kW power with 1.15 Nm torque at 6000 rpm. Featuring absolute encoder, natural cooling, and IP65/IP67 protection, it ensures reliable performance in industrial automation.
1FK7032-2AK71-1FA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1FA2 is part of the SIMOTICS S-1FK7 family, a series of compact synchronous motors engineered to deliver reliable performance in modern industrial environments. This exclusive motor offers a nominal power of 0.5 kW, a rated torque of 1.15 Nm at 100K, and operates at speeds up to 6000 rpm. Built for natural cooling, it ensures efficient heat dissipation through the motor surface without the need for external cooling components. With a frame size IMB5 and a rotatable power connector, it provides both flexibility and durability, while the IP65/IP67 protection guarantees dependable operation in demanding environments.
Equipped with an AM22DQ absolute encoder featuring 22-bit + 12-bit multiturn resolution and DRIVE-CLiQ interface, the motor ensures precise feedback for speed and position control. The shaft with fitted key offers secure mechanical integration, and the absence of a holding brake reduces complexity in applications where it is not required. This design makes the motor suitable for high-accuracy and dynamic motion tasks across diverse industries.
Overview
SIMOTICS S-1FK7 motors are renowned for their compact build, wide configuration range, and adaptability. They can be seamlessly combined with SINAMICS S120 or S220 drive systems to create a powerful solution with extended functionality. These motors provide excellent overload capacity, ensuring stable operation even under variable load conditions.
Benefits
- Compact structure enables space-saving installation
- High power density ensures excellent efficiency
- Flexible encoder and gearbox options for various applications
- Dynamic response with low rotor inertia (High Dynamic versions)
- Stable closed-loop control properties for demanding loads (High Inertia versions)
Application
- Machine tools and CNC equipment
- Robotics and automated handling systems
- Packaging, plastics, and textile machines
- Wood, glass, ceramics, and stone processing
- Printing and auxiliary axis applications
Download
Product Code: 1FK7032-2AK71-1FA2
More Siemens products at Turll.com
| Weight | 2.702 kg |
|---|
