1FK7032-2AK71-1PH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1PH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1PH2 belongs to the SIMOTICS S-1FK7 family of compact synchronous motors, engineered for precision, durability, and versatile performance in modern industrial automation. This exclusive motor delivers a nominal power of 0.5 kW with a rated speed of 6000 rpm and torque of 1.15 Nm, making it highly suitable for a broad range of machinery. It features natural cooling, a rotatable power connector, a two-pole resolver with DRIVE-CLiQ interface, and a smooth shaft design with an integrated holding brake. With a high degree of protection (IP65 on the motor body and IP67 at the drive end flange), this model ensures long-lasting operation even in challenging environments.

SIMOTICS S-1FK7 motors are designed with compact construction and high power density, allowing efficient space utilization without compromising performance. They can be seamlessly integrated with SINAMICS S120 or S220 drive systems, forming a powerful and intelligent drive solution for advanced applications. Thanks to integrated encoder options, users benefit from precise speed and position control tailored to demanding automation requirements. The robust construction, combined with efficient heat dissipation, enables continuous operation with minimal maintenance needs.

Overview

The SIMOTICS S-1FK7 range provides outstanding adaptability for diverse applications. With a wide selection of variants including Compact, High Dynamic, and High Inertia designs, users can choose the right configuration for their specific load requirements. Compact versions offer space-saving installation, High Dynamic motors deliver exceptional acceleration due to low rotor inertia, while High Inertia models provide stability under fluctuating loads. This flexibility ensures reduced commissioning effort and reliable operation.

Benefits

• Compact dimensions with excellent power-to-size ratio
• Highly flexible configurations for universal use
• Low rotor inertia for dynamic performance
• Stable control characteristics for variable load conditions
• Reduced optimization efforts during commissioning

Applications

• Machine tools and precision equipment
• Robotics and automated handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1PH2
