1FK7032-2AK71-1QB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1QB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1QB2 SIMOTICS S motor is a premium synchronous servo motor designed to deliver superior performance and long-lasting reliability in advanced automation systems. With a rated power of 0.5 kW, a torque of 1.15 Nm at 100K, and a nominal speed of 6000 rpm, this compact motor provides excellent power density in a small footprint. It is naturally cooled, features IMB 5 design for flexible installation, and is equipped with a rotatable power connector. The motor integrates an absolute single-turn encoder with DRIVE-CLiQ interface, offering precise speed and position feedback. A robust holding brake is included, and its protection level is IP65 with the drive-end flange rated at IP67, ensuring reliable operation even in challenging industrial environments.

The SIMOTICS S-1FK7 family of motors is known for its compact construction, flexibility, and adaptability across a wide range of industries. Thanks to its modular encoder options, gearbox compatibility, and scalability, the motor can be tailored to meet the increasing demands of modern machines. By combining this motor with SINAMICS S120 or S220 drive systems, users can achieve a powerful automation solution with outstanding functionality and control. The high overload capacity and rugged construction of this motor make it suitable for continuous operation without external cooling, while maintaining optimal performance levels.

Overview

The SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors designed for applications that require compact design, high performance, and exceptional reliability. The product range includes options for compact, high dynamic, and high inertia variants, each providing distinct advantages for specific use cases. This flexibility allows engineers to integrate the right motor into their system design with minimal effort.

Benefits

• Compact design for space-saving installation and high power density
• Wide adaptability for universal industrial applications
• Excellent dynamic response due to low rotor inertia
• Robust closed-loop control for applications with high or variable inertia
• Reduced optimization and commissioning effort

Applications

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing equipment
• Auxiliary axes in automation

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1QB2
