1FK7032-2AK71-1UB0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
$1,204.99
The SIEMENS 1FK7032-2AK71-1UB0 SIMOTICS S-1FK7 synchronous motor combines compact design, 0.5 kW power, 1.15 Nm torque, and precise resolver feedback. Engineered for automation systems, it ensures efficient, durable, and reliable motion control.
1FK7032-2AK71-1UB0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1UB0 SIMOTICS S-1FK7 synchronous motor represents an advanced and reliable solution for high-performance automation environments. This compact permanent-magnet motor delivers a rated power of 0.5 kW with a nominal torque of 1.15 Nm at 6000 rpm, offering exceptional precision and stability in demanding motion control applications. The motor operates on a 600V DC supply and is naturally cooled, allowing heat dissipation through the surface for consistent and efficient operation. Designed with an IMB 5 structure, it supports both IM V1 and IM V3 mounting positions, ensuring flexibility during installation.
This exclusive motor features a multi-pole resolver with a DRIVE-CLiQ interface for accurate feedback and synchronization with advanced SINAMICS S120 or S220 drive systems. The shaft with a feather key and tolerance N provides reliable mechanical coupling, while the integrated holding brake enhances safety and control in dynamic applications. The rotatable power connector simplifies integration, and the IP64 protection rating ensures dependable operation even in challenging industrial conditions.
Overview
SIMOTICS S-1FK7 motors are well known for their compact design and adaptability. The series includes multiple motor variants that meet diverse industrial requirements, combining advanced technology with outstanding energy efficiency. The integrated encoder options and mechanical versatility make them suitable for a wide range of automated systems and machinery. They are optimized for precision, dynamic performance, and long service life.
Benefits & Applications
- Compact and efficient design with high power density
- Adaptable to various industrial automation environments
- Excellent performance with high overload capacity
- Easy configuration with SINAMICS drive systems
- Ideal for use in machine tools, robotics, and material handling
- Suitable for packaging, printing, wood, glass, and textile machinery
Download
Product Code: 1FK7032-2AK71-1UB0
More Siemens products at Turll.com
| Weight | 3.001 kg |
|---|
