1FK7033-4CK71-1QA2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7033-4CK71-1QA2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CK71-1QA2 SIMOTICS S-1FK7 synchronous motor is an advanced high-performance solution designed for modern automation systems that require efficiency, compactness, and reliability. This exclusive model from the SIMOTICS S-1FK7 series delivers a nominal power of 0.57 kW and a torque of 1.3 Nm at 6000 rpm, ensuring smooth and precise operation in a variety of industrial applications. Operating at 600 V DC and naturally cooled, it provides consistent thermal stability and dependable performance under continuous load conditions.

Its IMB 5 frame design with a rotatable power connector allows flexible mounting in multiple orientations, while the integrated 20-bit single-turn absolute encoder (AS20DQI) with DRIVE-CLiQ interface ensures highly accurate feedback for position and speed control. The motor’s robust construction features IP65 protection with an IP67 flange, making it ideal for environments exposed to dust or moisture. The smooth shaft with fitted key, tolerance N, and absence of a holding brake offer mechanical simplicity and low maintenance requirements.

Overview

The SIMOTICS S-1FK7 family of synchronous motors is recognized for its precision engineering and adaptability. These compact, permanent-magnet motors can be configured with different encoder types and gearboxes, providing flexibility to meet specific system requirements. Combined with SINAMICS S120 or S220 drive systems, they form a dynamic and efficient motion control solution suitable for both general-purpose and high-demand operations.

Benefits & Applications

• Compact structure with high power density for space-saving installations
• Exceptional reliability and performance across a wide range of industrial uses
• Dynamic response and stability under variable load conditions
• Easy commissioning and integration with SINAMICS drive systems
• Perfect for machine tools, robotics, material handling, packaging, and textile equipment
• Also suitable for wood, glass, ceramics, and printing machinery

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1QA2
