1FK7033-4CK71-1QH1-ZJ29 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7033-4CK71-1QH1-ZJ29 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CK71-1QH1-ZJ29 SIMOTICS S-1FK7 synchronous motor is a high-performance industrial motor engineered for precision, efficiency, and reliability. Delivering a power output of 0.57 kW and a rated torque of 1.3 Nm at 6000 rpm, this naturally cooled motor is designed for use in demanding automation environments. Its IMB 5 frame configuration with a rotatable power connector and integrated holding brake ensures versatile mounting options and easy installation in confined spaces.

This exclusive motor model features an absolute single-turn 20-bit encoder with DRIVE-CLiQ interface, ensuring precise feedback and smooth synchronization with SINAMICS S120 or S220 drive systems. The smooth shaft with tolerance class N, IP65 protection, and integrated planetary gearbox ALPHA SP+ SP 060S-MF1 (1-stage, ratio i=10) make it ideal for high-accuracy applications that demand exceptional motion control and stability. The rugged construction and thermal design enable consistent performance with high overload capacity, even under continuous operation.

Overview

The SIMOTICS S-1FK7 motor family offers compact permanent-magnet synchronous motors adaptable to a wide range of applications. Combined with SINAMICS drive systems, these motors provide powerful functionality, fast response, and advanced control. Their design allows heat dissipation through the housing, eliminating the need for external cooling and ensuring maximum reliability and operational efficiency.

Benefits & Applications

• Compact, space-saving construction with high power density
• Reliable performance across industrial automation setups
• Precise feedback with integrated 20-bit encoder and DRIVE-CLiQ interface
• Compatible with machine tools, robotics, and packaging machinery
• Excellent dynamic response and load handling capabilities
• Long service life with minimal maintenance requirements

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1QH1-ZJ29
