1FK7034-2AK71-1CH1-ZJ29 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AK71-1CH1-ZJ29 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AK71-1CH1-ZJ29 SIMOTICS S-1FK7 synchronous motor is a high-efficiency permanent-magnet drive engineered for precision, durability, and flexibility in modern industrial environments. With a rated power output of 0.63 kW and a torque of 1.6 Nm at 6000 rpm, this compact model provides exceptional motion control while maintaining a small installation footprint. Its naturally cooled IMB 5 construction ensures reliable heat dissipation through the housing surface, allowing operation without additional cooling systems.

This version features an integrated 24-bit absolute encoder with a 12-bit multi-turn function via the Drive-CLiQ interface (AM24DQI), enabling precise positioning and smooth synchronization. The rotatable power connector simplifies wiring in restricted spaces, while the smooth shaft design with holding brake delivers secure mechanical performance. Designed for harsh industrial conditions, the motor’s IP65 protection rating guarantees resistance to dust and water ingress, ensuring consistent operation even under demanding workloads.

Overview

SIMOTICS S-1FK7 motors are compact, high-performance synchronous motors that combine precision and power density. Their modular design supports a wide selection of encoders, gearboxes, and accessories to accommodate specific industrial tasks. This unit is paired with an ALPHA SP+ SP 060S-MF1 planetary gearbox (1 stage, ratio 10), which enhances torque transfer and overall system efficiency.

Benefits & Applications

• Compact, space-efficient motor with high torque performance
• Seamless integration with SINAMICS S120/S220 drive systems
• Reliable closed-loop speed and position control
• Flexible installation due to rotatable connector and IMB 5 mounting
• Ideal for robotics, packaging, printing, and machine tools
• Low maintenance and designed for extended operational life

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1CH1-ZJ29
