The SIEMENS SIMOTICS S 1FK7034-2AK71-1QB0-ZN05 is a high-performance synchronous servo motor engineered for exceptional accuracy, speed, and operational reliability. With a rated power of 0.63 kW and a torque of 1.6 Nm at 6000 rpm, this naturally cooled motor provides excellent efficiency and responsiveness. It is built with an IMB 5 mounting design (IM V1, IM V3) and features a rotatable power connector for flexible installation. Equipped with an absolute single-turn 20-bit encoder using the Drive-CLiQ interface (AS20DQI), it ensures precise position and speed feedback. This model also includes a holding brake and offers IP64 protection, making it suitable for a broad range of industrial environments.

Overview

The SIMOTICS S-1FK7 motor family from SIEMENS represents the next generation of compact, permanent-magnet synchronous motors. Each unit is optimized for demanding automation systems, combining outstanding performance with reduced installation space. These motors integrate seamlessly with the SINAMICS S120/S220 drive systems, forming a unified motion solution for high-precision applications. Their built-in encoder technology delivers dependable speed and position control, allowing smooth motion sequences even under dynamic load conditions.

Heat dissipation occurs through the motor surface, eliminating the need for external cooling systems. This design enhances system simplicity while maintaining a high overload capacity. The compact construction ensures easy integration in machine layouts where space is critical, without compromising performance or stability.

Benefits

• Extremely high power density enables compact, space-saving installations.
• Wide adaptability for multiple automation and industrial tasks.
• High overload capability ensuring long-term reliability and consistent performance.
• Integrated encoder systems for precise control and feedback.
• Optional holding brake for enhanced operational safety.

Applications

• Machine tools and robotics
• Handling and positioning systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing and auxiliary axis automation

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1QB0-ZN05
