1FK7034-2AK71-1RG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7034-2AK71-1RG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S Synchronous Motor 1FK7034-2AK71-1RG1-ZJ09 represents a new generation of high-performance motion control technology, combining compact design, precision engineering, and energy efficiency. With a rated power output of 0.63 kW and a torque of 1.6 Nm at a nominal speed of 6000 rpm, this synchronous motor offers exceptional performance for demanding automation environments. Its naturally cooled IMB 5 design (IM V1, IM V3) ensures consistent thermal stability without external cooling requirements, making it highly reliable for continuous operation. The integrated absolute encoder AM20DQI provides accurate position feedback with 20-bit + 12-bit resolution, guaranteeing smooth synchronization and control accuracy across complex applications.

Overview

The SIMOTICS S-1FK7 motor series from SIEMENS is designed for versatility and precision in industrial motion systems. Built with a permanent-magnet rotor, the 1FK7 line delivers high torque density in a compact form factor, enabling space-saving integration into machinery. When paired with SINAMICS S120 or S220 drive systems, the result is a complete motion solution that ensures seamless communication, fast response times, and exceptional dynamic performance. The 1FK7 motors are maintenance-free and optimized for direct mounting, supporting a wide range of operating conditions with dependable mechanical robustness and efficiency.

Design and Benefits

This model includes a smooth shaft without holding brake, IP65 protection rating, and rotatable power connector for flexible installation. The addition of an ALPHA SP+ SP 060S-MF1 planetary gear unit (ratio i = 10) provides superior torque transmission and reduced backlash, ideal for precision machinery. The SIMOTICS S Compact variant offers remarkable power density for limited spaces, while maintaining excellent thermal management. The result is a motor with long service life, low vibration, and consistent operational stability across continuous load cycles.

Applications

The 1FK7034-2AK71-1RG1-ZJ09 is suitable for numerous automation systems such as CNC machines, packaging equipment, robotics, material handling, textile, printing, and woodworking machinery. Its adaptability and integration capability make it the preferred solution for industries requiring high repeatability, positioning accuracy, and dynamic control.

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1RG1-ZJ09
