1FK7034-2AK71-1UA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,103.19
The SIEMENS 1FK7034-2AK71-1UA0 SIMOTICS S synchronous motor delivers precise motion control with a rated power of 0.63 kW and 6000 rpm speed. Built for natural cooling and IP64 protection, it combines efficiency, durability, and flexibility for industrial automation systems requiring high reliability and smooth operation.
1FK7034-2AK71-1UA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7034-2AK71-1UA0 is a compact and high-performance synchronous motor designed to deliver precision, reliability, and superior efficiency in industrial automation environments. With a nominal power output of 0.63 kW, a rated speed of 6000 rpm, and a torque of 1.6 Nm at 100K, this motor ensures stable operation under continuous duty.
Built for naturally cooled performance and constructed in an IMB5 flange-mounted design, it offers excellent mechanical stability and smooth operation. Its rotatable multi-pole power connector and integrated DRIVE-CLiQ interface provide seamless communication with SIEMENS drive systems, enabling precise control and flexible configuration. The motor’s robust IP64 protection ensures durability in demanding environments, making it ideal for diverse industrial applications.
Overview
The SIMOTICS S-1FK7 series represents the next generation of SIEMENS permanent-magnet synchronous motors. These motors are engineered for exceptional flexibility and scalability, offering a wide range of frame sizes, encoder options, and mechanical variants. When combined with SINAMICS S120 or S220 drive systems, the 1FK7 motors form a powerful motion control solution capable of supporting the most dynamic and precision-driven industrial operations. The integrated encoder systems allow for accurate position and speed feedback, enabling reliable closed-loop control in automated production lines.
Designed for operation without external cooling, heat is efficiently dissipated through the motor housing, ensuring long service life and consistent performance under continuous loads. The 1FK7 series also features a high overload capacity, making it suitable for applications with frequent acceleration and deceleration cycles.
Benefits
The SIMOTICS S-1FK7 Compact motors provide a space-saving installation with an exceptionally high power density, making them ideal for systems where efficiency and compactness are critical. The High Dynamic variants offer extremely fast acceleration due to a low rotor moment of inertia, while the High Inertia versions ensure robust control for high or variable load moments. Together, these configurations meet the diverse requirements of modern machinery and automation processes.
Applications
This motor series is widely used in machine tools, robotics, packaging systems, and material handling. It also performs exceptionally in industries such as wood, glass, ceramics, and textile manufacturing, as well as printing and auxiliary axes applications. Each model delivers precise torque, consistent power, and long-term reliability that SIEMENS is known for.
Download
Product Code: 1FK7034-2AK71-1UA0
More Siemens products at Turll.com
| Weight | 3.702 kg |
|---|
