1FK7040-2AK71-1PH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,219.54
The SIEMENS SIMOTICS S 1FK7040-2AK71-1PH0 is a compact synchronous motor built for precision, efficiency, and versatility. With a rated power of 0.69 kW and 6000 rpm speed, it offers reliable torque, IP64 protection, and smooth operation for a wide range of automation and motion control applications.
1FK7040-2AK71-1PH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7040-2AK71-1PH0 is a high-performance synchronous motor designed to deliver exceptional reliability, precision, and energy efficiency in modern automation systems. With a rated power of 0.69 kW and a rated speed of 6000 rpm, this compact motor provides smooth operation and consistent torque performance even under demanding industrial conditions. It operates at a DC link voltage of 600V and delivers a torque of 1.6 Nm at 100K. The naturally cooled IMB 5 design ensures efficient heat dissipation, while the integrated holding brake and IP64 protection rating guarantee long-lasting durability and performance stability in diverse operating environments.
Overview
The SIMOTICS S-1FK7 motor family from SIEMENS is renowned for its compact construction, high power density, and flexible configuration options. These permanent-magnet synchronous motors can be combined with SINAMICS S120 or S220 drive systems to create a robust motion control solution with superior functionality. Depending on application requirements, users can select from multiple encoder systems for precise speed and position feedback. The design allows the motor to operate without external cooling, with heat dissipated through its optimized housing structure. Its robust construction ensures high overload capability and long operational life, even in continuous operation environments.
Benefits
SIMOTICS S-1FK7 Compact motors offer space-saving installation and a wide power range for universal applications. High Dynamic motors provide exceptional dynamic response due to their low rotor moment of inertia, ideal for high-speed precision systems. Meanwhile, High Inertia motors deliver superior stability in applications with fluctuating load conditions, minimizing setup and commissioning effort. Together, these variants offer a complete and adaptable motor solution that meets the increasing performance demands of advanced machinery.
Applications
The 1FK7040-2AK71-1PH0 motor is widely used in machine tools, robotics, handling systems, packaging equipment, printing machinery, and material processing industries such as wood, glass, ceramics, and plastics. Its precise control and efficiency make it ideal for automated systems requiring consistent torque, rapid acceleration, and compact mechanical integration.
Download
Product Code: 1FK7040-2AK71-1PH0
More Siemens products at Turll.com
| Weight | 3.6 kg |
|---|
