1FK7042-2AC71-1FB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7042-2AC71-1FB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S Synchronous Motor 1FK7042-2AC71-1FB0 is a high-efficiency drive solution designed for industrial applications requiring precision, reliability, and durability. This motor delivers a rated power of 0.59 kW at 2000 rpm with a torque of 3 Nm, ensuring stable performance in various motion control environments. Built with a naturally cooled system and IP64 degree of protection, it provides dependable operation even in challenging industrial conditions. The integrated 22-bit + 12-bit multiturn absolute encoder with DRIVE-CLiQ interface enhances accuracy and control, while the holding brake feature ensures maximum safety and reliability during operation. Its compact frame design (IMB5/IMV1/IMV3) and rotatable power connector simplify installation and maintenance.

Overview

The SIMOTICS S-1FK7 series represents the new generation of compact, permanent-magnet synchronous motors by SIEMENS. Offering exceptional performance, flexibility, and energy efficiency, these motors can be seamlessly integrated into modern automation systems. The 1FK7 range supports multiple encoder options, gear combinations, and mechanical interfaces, allowing perfect customization for a wide range of industrial applications. The motors operate without external cooling, effectively dissipating heat through the housing surface, resulting in low maintenance and extended service life. When combined with the SINAMICS S120 or S220 drive systems, the SIMOTICS S-1FK7 motors form a powerful, dynamic, and intelligent motion solution that delivers smooth operation and high responsiveness.

Benefits

• Compact construction with high power density for space-saving installation.
• Versatile performance suitable for universal industrial use.
• Flexible integration with SIEMENS SINAMICS drive systems.
• Enhanced precision and efficiency through advanced encoder technology.
• Available in multiple dynamic and inertia classes to match diverse load requirements.

Applications

• Machine tools and precision engineering systems
• Robotic arms and automated handling systems
• Wood, glass, ceramics, and stone processing equipment
• Packaging, textile, and plastic machinery
• Printing machines and auxiliary automation axes

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AC71-1FB0
