1FK7042-2AC71-1UB2 SIEMENS Exclusive SIMOTICS S-1FK7 CT Synchronous Motor Original Brand New

1FK7042-2AC71-1UB2 SIEMENS Exclusive SIMOTICS S-1FK7 CT Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 CT synchronous motor, represents the pinnacle of industrial motor technology, combining compact design with exceptional performance. Delivering a nominal power of 0.59 kW at 2000 rpm and featuring a multi-pole resolver with DRIVE-CLiQ interface, this motor offers precise speed and position control for demanding automation applications. Naturally cooled and rated with an IP65 protection degree (IP67 on the DE flange), the motor ensures reliable operation even in harsh environments. The integrated holding brake, rotatable power connector, and robust shaft with feather key enhance versatility and ease of installation across multiple machine configurations.

Overview

The SIMOTICS S-1FK7 series consists of compact permanent-magnet synchronous motors designed for high adaptability and performance. These motors can be paired with SINAMICS S120 or S220 drive systems to deliver comprehensive functionality, making them ideal for modern machinery. With multiple gearbox and encoder options, the motors can be precisely tailored to meet the unique requirements of advanced industrial equipment. Their self-cooling design dissipates heat efficiently through the motor surface, providing high overload capacity without additional cooling systems.

Benefits

• Space-saving installation thanks to high power density
• Suitable for a wide range of industrial applications
• High dynamic response for motors with low rotor inertia
• Robust closed-loop performance for high or variable load inertia
• Minimal commissioning effort and easy disturbance compensation

Applications

• Machine tools and precision manufacturing
• Robotic arms and handling systems
• Woodworking, glass, ceramics, and stone machinery
• Packaging, plastics, and textile production
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AC71-1UB2
