1FK7042-2AF71-1RB1 Siemens SIMOTICS S-1FK7 Original Brand New
$1,697.30
1FK7042-2AF71-1RB1
Siemens SIMOTICS S SIMOTICS S-1FK7 1FK7-CT synchronous motor PN=0.82 kW UDC=600 V M0=3 Nm (100K); NN=3000 r/min; naturally cooled design MB 5 (IM V1, IM V3) flange 1 power connector rotatable absolute encoder 20 bit +12 bit multiturn with DRIVE-CLiQ interface (encoder AM20DQI) shaft with feather key, tolerance N with holding brake degree of protection IP65
[ez-toc]
Overview
SIMOTICS S‑1FK7 motors are compact permanent‑magnet synchronous motors. The available options, gearboxes and encoders, together with the expanded product range, mean that the SIMOTICS S‑1FK7 motors can be perfectly adapted to any application. They therefore also satisfy the permanently increasing demands of state‑of‑the‑art machine generations.
SIMOTICS S‑1FK7 motors can be combined with the SINAMICS S120 drive system to create a powerful system with high functionality. The integrated encoder systems for speed and position control can be selected depending on the application.
The motors are designed for operation without external cooling and the heat is dissipated through the motor surface. The SIMOTICS S‑1FK7 motors have a high overload capability.
Benefits
SIMOTICS S‑1FK7 Compact motors:
- Space‑saving installation due to extremely high power density
- For universal applications
- Wide range of motors
SIMOTICS S‑1FK7 High Dynamic motors:
- Extremely high dynamic response thanks to the very low rotor moment of inertia
SIMOTICS S‑1FK7 High Inertia motors:
- Robust closed‑loop control properties for high or variable load moment of inertia
- Minimal optimization and commissioning overhead for the compensation of disturbances
Application
- Machine tools
- Robots and handling systems
- Wood, glass, ceramics and stone working
- Packaging, plastics and textile machines
- Printing machines
- Auxiliary axes
1FK7042-2AF71-1RB1
Siemens SIMOTICS S SIMOTICS S-1FK7 1FK7-CT synchronous motor PN=0.82 kW UDC=600 V M0=3 Nm (100K); NN=3000 r/min; naturally cooled design MB 5 (IM V1, IM V3) flange 1 power connector rotatable absolute encoder 20 bit +12 bit multiturn with DRIVE-CLiQ interface (encoder AM20DQI) shaft with feather key, tolerance N with holding brake degree of protection IP65
Visit 1FK7042-2AF71-1RB1
For more our products visit turll.com
| Weight | 4.900 kg |
|---|---|
| Dimensions | 1 × 1 × 1 mm |
