1FK7044-4CF71-1BA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,781.90
The SIEMENS SIMOTICS S 1FK7044-4CF71-1BA2 is a 1.2 kW synchronous motor designed for high precision, featuring 4.5 Nm torque, natural cooling, 24-bit absolute encoder, and IP65/IP67 protection for advanced motion control systems.
1FK7044-4CF71-1BA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7044-4CF71-1BA2 is a high-precision synchronous motor engineered to deliver outstanding performance, durability, and flexibility in a wide range of industrial motion control applications. With a nominal power of 1.2 kW and a rated torque of 4.5 Nm at 3000 rpm, this motor ensures precise motion and consistent operation even under demanding production conditions. It operates on a 600V DC link voltage and features natural cooling, making it both efficient and maintenance-friendly. The motor’s IP65/IP67 protection rating guarantees excellent resistance to dust, moisture, and environmental challenges, ensuring long-term reliability.
Equipped with a single-turn 24-bit absolute encoder (AS24DQI) featuring a DRIVE-CLiQ interface, the 1FK7044-4CF71-1BA2 offers superior position feedback and control accuracy. The rotatable power connector and standardized flange design (IMB 5 / IM V1 / IM V3) allow for flexible installation in compact machine configurations. The motor comes with a shaft fitted key with tolerance N and is supplied without a holding brake, ideal for applications requiring fast response and minimal inertia.
Overview
The SIMOTICS S-1FK7 motor series by Siemens represents the next generation of compact permanent-magnet synchronous motors. These motors combine high torque density, precise speed control, and easy integration with Siemens SINAMICS S120 and S220 drive systems. They are designed for direct mounting and effective heat dissipation via the housing surface, enabling reliable operation without the need for external cooling systems. The series offers a wide range of options, encoders, and gearboxes, ensuring each motor can be precisely matched to specific industrial requirements.
Benefits
- Compact and space-saving design with exceptional power density
- Suitable for a broad spectrum of industrial applications
- Available in multiple performance variants: Compact, High Dynamic, and High Inertia
- High reliability with minimal commissioning and configuration effort
- Precise speed and torque control through integrated encoder systems
Applications
- Machine tools and robotics
- Handling systems and automation cells
- Wood, glass, ceramics, and stone processing equipment
- Packaging, plastic, and textile machinery
- Printing and auxiliary drive systems
Download
Product Code: 1FK7044-4CF71-1BA2
Discover more Siemens products at Turll.com
| Weight | 7.401 kg |
|---|
