The SIEMENS SIMOTICS S 1FK7044-4CF71-1FB0 is an exclusive high-precision synchronous motor featuring 1.2 kW output, 4.5 Nm torque, natural cooling, DRIVE-CLiQ encoder, and IP64 protection for advanced automation systems.
The SIEMENS SIMOTICS S 1FK7044-4CF71-1FB0 is a high-performance synchronous motor designed to deliver exceptional reliability, precision, and efficiency in industrial automation. With a rated power of 1.2 kW and a rated torque of 4.5 Nm at 3000 rpm, this motor ensures smooth operation and stable performance even under demanding conditions. It features a naturally cooled design, allowing efficient heat dissipation through its compact frame. The rotatable power connector, absolute encoder with DRIVE-CLiQ interface, and integrated holding brake make it a versatile choice for modern servo systems. Built with an IP64 protection rating, this motor offers reliable operation in industrial environments requiring both accuracy and durability.
The SIMOTICS S-1FK7 family represents Siemens’ leading technology in compact synchronous servo motors. Designed for maximum flexibility, the series combines robust construction with advanced performance features, making it suitable for a wide variety of industrial applications. The 1FK7044-4CF71-1FB0 can be easily integrated with SINAMICS S120 / S220 drive systems to form a powerful motion control solution. Its built-in encoder provides precise speed and position feedback for closed-loop control, while its compact dimensions enable installation where space is limited. The motor’s high overload capacity ensures consistent operation during acceleration or dynamic load changes, guaranteeing stable torque and high efficiency throughout extended operation.
The SIMOTICS S-1FK7 HD motors are engineered for high dynamic response with a very low rotor moment of inertia, ensuring superior acceleration and control accuracy. Users benefit from flexible configuration options, including various encoder types, gear ratios, and mounting positions. This design approach supports seamless adaptation to diverse systems such as machine tools, packaging equipment, robotics, and precision handling applications. The motor’s optimized housing contributes to vibration resistance, long-term stability, and easy maintenance. Its overall design minimizes commissioning effort and simplifies integration into automation networks. Industries such as textile manufacturing, printing, glass processing, and auxiliary motion control rely on this model for precise, repeatable performance and extended service life.
Product Code: 1FK7044-4CF71-1FB0
Discover more Siemens products at Turll.com
| SKU / Model | 1FK7044-4CF71-1FB0 |
|---|---|
| Weight | 7.7 kg |
