1FK7044-4CH71-1CG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7044-4CH71-1CG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7044-4CH71-1CG0 is a compact and high-precision synchronous motor engineered for modern automation and motion control systems. With a rated power of 1.4 kW, a rated speed of 4500 rpm, and a torque of 4.5 Nm, this model offers outstanding performance and stability in a wide range of industrial applications. The motor operates at 600 V DC and features a naturally cooled design with IP64 protection, ensuring reliable operation in challenging environments. Its plain shaft construction, rotatable power connector, and AM24DQI absolute encoder with DRIVE-CLiQ interface provide precise feedback and flexible installation for both standard and dynamic machinery setups.

This SIMOTICS S 1FK7-HD variant is designed for applications requiring both speed and accuracy, allowing for smooth integration with SINAMICS S120 or S220 drive systems. The encoder system enables high-resolution position and speed control, improving machine efficiency and repeatability. Built with durable materials and precision manufacturing, the 1FK7044-4CH71-1CG0 delivers long-term operational reliability with minimal maintenance requirements.

Overview

SIMOTICS S-1FK7 motors represent Siemens’ commitment to high-performance servo technology. These permanent-magnet synchronous motors offer compact dimensions, high torque density, and energy-efficient operation. Thanks to a wide range of available variants, including compact, high-dynamic, and high-inertia types, the SIMOTICS S-1FK7 family can be adapted perfectly to any motion control system. They provide optimal flexibility for use across diverse industrial applications.

Benefits

• Space-saving design due to exceptional power density
• Universal suitability across a wide range of industries
• Extremely high dynamic response for precise motion
• Reliable closed-loop control even under variable load conditions
• Minimal tuning and commissioning effort for system optimization

Applications

• Machine tools and CNC systems
• Robotics and automated handling equipment
• Wood, glass, ceramics, and stone processing machinery
• Packaging, plastic, and textile machines
• Printing and auxiliary industrial axes

Download

Data Sheet (PDF)

Product Code: 1FK7044-4CH71-1CG0
