1FK7060-2AC71-1CH0-ZV42 SIEMENS Exclusive SIMOTICS S 1FK7 Synchronous Motor Original Brand New

1FK7060-2AC71-1CH0-ZV42 SIEMENS Exclusive SIMOTICS S 1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7060-2AC71-1CH0-ZV42 is a premium SIMOTICS S 1FK7 synchronous motor engineered for high-performance automation applications. Designed with a compact permanent-magnet construction, this motor delivers an impressive 1.1 kW output with a rated speed of 2000 rpm. Featuring a naturally cooled IMB 5 design and a robust flange 1 interface, it ensures reliable operation even in demanding industrial environments. The integrated 24-bit single-turn and 12-bit multi-turn encoder with Drive-CLiQ interface provides precise speed and position control, essential for high-accuracy machinery. Its smooth shaft with tolerance N and holding brake ensures secure operation with minimal mechanical play.

Equipped with an ALPHA LP+ planetary gearing stage (I=10) and fitted key, the motor combines durability and performance in a space-saving design. The IP64 protection class allows the motor to operate safely in environments prone to dust and moisture. When paired with SINAMICS S120/S220 drive systems, the motor provides exceptional functionality, enabling high-dynamic and high-inertia operation to meet various machine requirements. Its high overload capacity and naturally cooled construction simplify installation and reduce maintenance needs.

Overview

The SIMOTICS S‑1FK7 series offers versatile solutions for modern automation. Compact motors provide exceptional power density for space-constrained applications, while high-dynamic models deliver fast response thanks to low rotor inertia. High-inertia variants offer robust closed-loop control for machines with variable or high load inertia, minimizing commissioning and compensation efforts. These motors are suitable for machine tools, robots, handling systems, and a wide range of manufacturing equipment including wood, glass, ceramics, stone, packaging, plastics, textiles, and printing machines.

Benefits

• Space-saving installation with high power density
• Wide range of motor configurations for universal applications
• Integrated encoder systems for precise speed and position control
• High dynamic response and robust closed-loop control
• Minimal commissioning effort and reliable disturbance compensation

Application

• Machine tools
• Robots and handling systems
• Wood, glass, ceramics, and stone processing machines
• Packaging, plastics, and textile machines
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1CH0-ZV42
