1FK7060-2AC71-1QG1-ZJ05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AC71-1QG1-ZJ05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The Synchronous Motor delivers exceptional precision and efficiency for advanced automation applications. Designed with a naturally cooled structure and IP65 protection, this high-performance motor ensures reliable operation in demanding environments. With a power rating of 1.1 kW, rated torque of 6 Nm, and speed up to 2000 rpm, it provides consistent motion control for dynamic industrial systems. Featuring an absolute single-turn 20-bit encoder with Drive-CLiQ interface and a smooth shaft design, this motor achieves accurate feedback and outstanding repeatability across every motion cycle.

Its integrated ALPHA SP+ SP 100S-MF1 planetary gear unit (J05) offers a single-stage reduction ratio of i = 7, enabling high torque transfer with minimal backlash and efficient energy use. The rotatable power connector and flange mount design (IMB 5) simplify installation in flexible layouts. The motor’s high overload capacity and maintenance-free construction make it ideal for continuous operation in automated production lines and robotic applications.

Overview

This represent the benchmark for compact, permanent-magnet synchronous motors that combine power density, durability, and intelligent control features. They can be easily integrated with SINAMICS S120/S220 drive systems to build high-performance motion platforms with superior functionality. The integrated encoder system ensures precise position and speed control, while the optimized magnetic circuit design supports outstanding torque utilization.

• Compact footprint for space-efficient installation
• Flexible adaptation through optional gearboxes and encoders
• High dynamic performance and fast acceleration
• Rugged mechanical structure for vibration-resistant operation
• Suitable for continuous industrial use without external cooling

Applications include: machine tools, packaging, robotics, handling systems, and precision manufacturing.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1QG1-ZJ05
