The SIEMENS 1FK7060-2AC71-1RH1-ZJ23 SIMOTICS S synchronous motor delivers 1.1 kW compact power, high-precision control with Drive-CLiQ encoder, and versatile application across industrial machinery.
The 1FK7-CT motor is a high-performance, compact permanent-magnet synchronous motor designed for modern industrial applications. The model delivers 1.1 kW of power with a nominal voltage of 600 V and a nominal torque of 6 Nm at 2000 rpm. Its naturally cooled design allows heat dissipation through the motor surface, eliminating the need for external cooling systems and ensuring reliable operation even in demanding environments.
Equipped with a rotatable power connector and an advanced 20-bit absolute encoder with 12-bit multi-turn functionality, this motor ensures precise speed and position control. The Drive-CLiQ interface guarantees seamless integration with SINAMICS S120 or S220 drives, providing a complete system solution with exceptional functionality. The smooth shaft is built to tolerance N and includes a holding brake, while the ALPHA SP+ planetary gearing stage (I=5) ensures efficient torque transmission without requiring a feather key.
The SIMOTICS S-1FK7 series is engineered for versatility, combining compact dimensions with high power density. These motors offer flexible adaptation through available options, gearboxes, and encoder systems, making them ideal for a wide range of industrial machines. High overload capacity and precise closed-loop control enable robust performance even under variable load conditions. The series supports universal applications and provides minimal optimization and commissioning overhead, reducing setup time for operators and engineers.
Product Code: 1FK7060-2AC71-1RH1-ZJ23
Discover more Siemens products at Turll.com.
| SKU / Model | 1FK7060-2AC71-1RH1-ZJ23 |
|---|---|
| Weight | 15.1 kg |
