1FK7060-2AF71-1BB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1BB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7060-2AF71-1BB2 is a high-performance synchronous servo motor engineered for precision motion and demanding automation applications. This compact motor delivers outstanding efficiency with a rated power of 1.5 kW and a nominal torque of 6 Nm. Operating at 3000 rpm under a 600 V DC supply, it is designed for maximum stability and durability, offering a naturally cooled construction in an IMB5 (IM V1, IM V3) flange design. The 1FK7060-2AF71-1BB2 is equipped with a single-turn 24-bit absolute encoder using the advanced Drive-CLiQ interface, ensuring smooth communication and high-resolution feedback for precise positioning and speed control.

The rugged design includes a rotatable power connector and an IP65/IP67 protection class, providing resistance against dust and moisture. Its integrated holding brake and feather-key shaft ensure mechanical security and superior torque transmission. The motor’s naturally cooled body effectively dissipates heat, maintaining stable operation even under continuous high-load conditions. This makes it a reliable choice for automation systems that require consistent torque and minimal maintenance.

Overview

The SIMOTICS S-1FK7 series represents SIEMENS’ most advanced generation of compact permanent-magnet synchronous motors. These motors are ideal for flexible use in machine tools, robotics, and motion control systems. The available encoders, gear units, and mechanical variants allow precise adaptation to any industrial environment. When paired with SINAMICS S120 or S220 drive systems, the 1FK7 family forms a powerful automation solution with exceptional control accuracy and energy efficiency.

Benefits

• Compact and lightweight design for space-saving installation
• High power density enabling superior torque output
• Wide selection of configurations for universal applications
• Exceptional dynamic response for fast acceleration and deceleration
• Stable closed-loop control even under fluctuating loads
• Designed for long life and low maintenance requirements

Applications

• Machine tools and precision positioning systems
• Robotics, handling, and assembly automation
• Wood, glass, ceramics, and stone processing equipment
• Packaging, plastics, and textile machinery
• Printing machines and auxiliary motion axes

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1BB2
