1FK7060-2AF71-1CG0-ZY84 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1CG0-ZY84 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S motor with the reference 1FK7060-2AF71-1CG0-ZY84 is a high-quality synchronous servo unit designed for precision motion control in demanding industrial environments. This premium model delivers exceptional output performance at 1.5 kW with a nominal torque of 6 Nm and a rated speed of 3000 rpm. Engineered with a naturally cooled frame in IMB 5 construction, it provides efficient thermal behavior without requiring external cooling systems. The unit incorporates a smooth shaft with tolerance class N and is supplied without a holding brake, making it suitable for a wide variety of machine configurations where minimal mechanical resistance and controlled acceleration profiles are necessary.

Equipped with a 24-bit absolute encoder combined with a 12-bit multiturn system using DRIVE-CLiQ technology, the motor supports highly accurate feedback, ensuring stable speed control and precise positioning. Its rotatable power connector simplifies installation within restricted cabinet spaces, while the robust IP64 enclosure offers reliable protection against dust and splashing water. This model includes the Y84 configuration, enabling customer-specific details on the rating plate for refined identification and asset tracking. As part of the SIMOTICS S-1FK7 family, this motor is built to deliver durability, responsiveness and long-term operational efficiency across a broad spectrum of machinery.

Overview

The SIMOTICS S-1FK7 series consists of compact permanent-magnet synchronous motors developed to meet the evolving requirements of modern industrial systems. Through a wide range of options, encoders and gearbox compatibility, the motors can be precisely matched to their intended tasks, ensuring optimal performance and design flexibility. When integrated with SINAMICS S120 or S220 drive platforms, users gain access to an advanced motion control solution with extensive functionality and excellent dynamic characteristics.

Benefits

• High power density allowing space-efficient installation
• Broad selection of variants for universal applications
• Low rotor inertia for exceptional dynamic responsiveness in high-demand processes
• Stable closed-loop characteristics for varying load conditions
• Minimal commissioning effort and smooth compensation of operational disturbances

Application

• Machine tools
• Robotics and automated handling
• Wood, glass, ceramics and stone processing
• Packaging, plastics and textile equipment
• Printing and auxiliary machine operations

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1CG0-ZY84
