1FK7060-2AF71-1FA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AF71-1FA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7 motor with code 1FK7060-2AF71-1FA1 is a high-performance synchronous motor engineered to deliver reliable torque, stable speed characteristics, and excellent operational efficiency. This model features a rated power of 1.5 kW, a DC link voltage of 600 V, and a continuous torque of 6 Nm at 100K. With its naturally cooled design and IMB 5 mounting configuration, it provides strong mechanical stability while maintaining compact dimensions suitable for modern industrial machine layouts.

The motor is equipped with a rotatable power connector and an advanced absolute encoder system offering 22-bit plus 12-bit multiturn resolution through a DRIVE-CLiQ interface. This high-precision feedback mechanism ensures improved motion accuracy and smooth performance, even in dynamic applications. Its shaft with a fitted key offers dependable power transmission, while the IP65 degree of protection secures the motor against dust and low-pressure water exposure, making it robust for demanding environments.

Overview

SIMOTICS S-1FK7 synchronous motors 1FK7060-2AF71-1FA1 are compact permanent-magnet motors designed to meet the needs of modern automation tasks. Their wide configuration options, encoder variations, and compatibility with multiple gearboxes make them suitable for a broad range of industries. When combined with the SINAMICS S120 or S220 drive systems, users benefit from a flexible, high-functionality motion control solution with exceptional adaptability.

These motors operate without external cooling, efficiently dissipating heat through their surface. Their construction ensures excellent overload capability, making them suitable for processes that require brief periods of increased torque. The optimized rotor design contributes to fast response behavior, while their structural robustness supports stable closed-loop control, especially in installations with varying load conditions.

Benefits

• High power density for space-efficient machine integration
• Versatile configuration options for universal applications
• Wide selection of motor variants for tailored system design
• Dynamic performance due to optimized rotor inertia
• Stable closed-loop characteristics for high-load operations
• Reduced commissioning time thanks to advanced control responsiveness

Application

• Machine tools and precision automation
• Robotics and advanced handling systems
• Wood, glass, ceramics, and stone processing
• Packaging and textile equipment
• Printing machinery
• Auxiliary axis configurations

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AF71-1FA1
