The SIEMENS 1FK7060-2AF71-1RA2 SIMOTICS S synchronous motor is a high-performance solution engineered for modern industrial automation systems requiring precision, stability, and long-term reliability. With a rated power of 1.5 kW and a torque of 6 Nm, this advanced motor is designed to deliver dependable performance in demanding motion applications. Its naturally cooled construction ensures consistent thermal management, while the IMB 5 mechanical design allows flexible mounting for a wide range of machine layouts.

This model features a rotatable power connector and a high-resolution absolute encoder system combining 20-bit single-turn and 12-bit multiturn technology, communicating via the DRIVE-CLiQ interface. The shaft uses a feather-key connection with tolerance class N. Without a holding brake, this motor supports applications prioritizing smooth continuous duty cycles. The device fulfills industrial protection requirements with an IP65 front face and an IP67 flange, making it suitable for environments where dust and water exposure must be controlled.

Overview

The SIMOTICS S-1FK7 series consists of compact, permanent-magnet synchronous motors built for high efficiency and adaptability. Their wide range of options—including encoder variations, mechanical configurations, and gearbox compatibility—enables optimization for many automation tasks. When combined with SINAMICS S120 or S220 drives, the motors form a powerful and versatile motion system.

The motors operate without external cooling equipment, relying on their optimized surface design for heat dissipation. This contributes to long service life and excellent overload capacity. Integrated feedback systems offer precise speed and position control, ensuring consistent behavior even under dynamic load changes.

Benefits

• High power density for compact machine integration
• Flexible configuration options for diverse applications
• Low-inertia variants for rapid acceleration
• High-inertia variants for stable control under varying loads
• Minimal commissioning effort due to robust control behavior

Application

• Machine tools
• Robotic systems and automated handling
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing machines
• Auxiliary axis applications

Download

Data Sheet (PDF)

Product Code:
1FK7060-2AF71-1RA2
