1FK7060-2AH71-1PB2 SIEMENS Exclusive SIMOTICS S Motor Original Brand New

1FK7060-2AH71-1PB2 SIEMENS Exclusive SIMOTICS S Motor Original Brand New

The SIEMENS 1FK7060-2AH71-1PB2 represents a refined generation of permanent-magnet synchronous drive technology engineered for applications that require consistent performance, high efficiency, and long-term reliability. This model belongs to the advanced SIMOTICS S-1FK7 family, a range known for its compact structure, versatile configuration options, and outstanding operational stability. Designed for use without external cooling, the motor dissipates heat through its surface, allowing integration into demanding environments while maintaining dependable thermal characteristics. With a continuous torque of 6 Nm, a nominal speed of 4500 rpm, and a 600 V DC link voltage rating, the unit offers a stable power profile for numerous precision-driven systems.

The motor features a naturally cooled IMB 5 design with multiple permissible mounting orientations such as IM V1 and IM V3, making it adaptable for a wide selection of engineering layouts. It includes a rotatable power connector, a robust 2-pole resolver with DRIVE-CLiQ interface for detailed feedback, and a shaft with a feather key manufactured to tolerance class N. An integrated holding brake enhances operational safety during downtime or maintenance conditions. With enclosure protection ratings of IP65 and IP67 on the drive-end flange, the device is well-suited for environments where exposure to dust or moisture cannot be avoided.

Overview

SIMOTICS S-1FK7 motors are engineered for versatility, providing configuration flexibility through various encoders, optional gearboxes, and an extensive range of mechanical variants. These motors combine seamlessly with SINAMICS S120 and S220 drive platforms, forming a capable motion system for modern automation requirements. Their compact geometry enables space-efficient installation, while their strong overload capacity supports dynamic operating profiles across numerous industrial tasks.

Benefits

• Compact construction enables reduced installation space while maintaining high output.
• Extensive motor range suitable for universal industrial requirements.
• High Dynamic variants offer remarkable responsiveness due to low rotor inertia.
• High Inertia versions maintain stable control performance with fluctuating load demands.
• Simplified commissioning with minimal disturbance compensation.

Application

• Machine tools and auxiliary axes
• Robotics and automated handling systems
• Material processing equipment
• Packaging, textile, plastic and printing machinery
• Wood, stone, ceramic and glass processing

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AH71-1PB2
