1FK7061-4CF71-1CH1-ZR72 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

1FK7061-4CF71-1CH1-ZR72 SIEMENS Exclusive SIMOTICS S-1FK7 Motor Original Brand New

The 1FK7061-4CF71-1CH1-ZR72 from SIEMENS is part of the renowned SIMOTICS S-1FK7 series, engineered to deliver high-precision motion performance for modern industrial machinery. This synchronous motor is designed to meet demanding mechanical and automation requirements, offering a versatile configuration that supports long-term system stability. With a power rating of 1.7 kW, a nominal speed of 3000 rpm, and a robust 6.4 Nm torque capability, it is suitable for dynamic tasks where accuracy, responsiveness, and mechanical efficiency must work together seamlessly. The naturally cooled IMB 5 construction allows the motor to dissipate heat effectively without requiring external cooling systems, making it ideal for compact machine layouts and continuous operation.

1FK7061-4CF71-1CH1-ZR72 Equipped with a 24-bit plus 12-bit multiturn absolute encoder featuring DRIVE-CLIQ interface technology, this motor ensures precise feedback, stable closed-loop control, and compatibility with a wide range of SIEMENS drive solutions. Its plain shaft with tolerance class N, holding brake, and IP65 degree of protection provide durability and mechanical reliability even under challenging production environments. The motor’s design supports consistent performance in automated systems where synchronization, acceleration, and accuracy are essential elements. Additional incremental encoder functionality (option R72) further enhances versatility in applications requiring detailed speed or positional feedback.

Overview

SIMOTICS S-1FK7 motors combine compact construction with optimized mechanical characteristics to provide an adaptable solution for various machine concepts. With extensive encoder options, gearbox compatibility, and multiple frame configurations, these motors fit easily into both new and existing system architectures. When paired with SINAMICS S120 or S220 drives, the result is a high-performance motion platform capable of delivering efficient control, significant flexibility, and reduced commissioning work. These motors are designed for surface cooling, possess high overload capacity, and maintain stable operation across extended duty cycles.

Benefits

• High power density for space-efficient integration in machinery.
• Suitable for numerous industrial applications with varied load requirements.
• Wide selection of models for tailored mechanical and operational needs.
• High Dynamic variants offer exceptional responsiveness due to low rotor inertia.
• High Inertia types ensure robust behavior under varying mechanical loads.
• Reduced optimization effort during commissioning and disturbance compensation.

Application

• Machine tools and precision cutting systems
• Robotics, handling systems, and automated assembly cells
• Wood, glass, ceramic, and stone fabrication equipment
• Packaging, plastic, and textile processing machinery
• Printing systems and auxiliary automation axes

Product Code: 1FK7061-4CF71-1CH1-ZR72 —
